2004 Volkswagen Passat GLX specs & colors

Starting MSRP
Current listing price
2004 Volkswagen Passat GLX

Showing the 2004 Volkswagen Passat 4dr Sdn GLX V6 Manual

Shop Now

Key specs

Color options


Slate Blue


Medium Prarie Tan

Medium Mocha


Crystal Blue


Cypress / Dark Cypress

Royal Blue





EPA Classification Mid-Size
Front Wheel Size 16 x 7 in
Rear Wheel Size 16 x 7 in
Spare Wheel Size 16 x 7 in
Front Wheel Material Alloy
Rear Wheel Material Alloy
Spare Wheel Material N/A
Cold Cranking Amps @ 0° F (Primary) N/A
Maximum Alternator Capacity (amps) 90
Engine Type Gas V6
Displacement 2.8L/169
SAE Net Horsepower @ RPM 190 @ 6000
SAE Net Torque @ RPM 206 @ 3200
EPA Fuel Economy Est - Hwy 28 MPG
Cruising Range - City 328.00 mi
EPA Fuel Economy Est - City 20 MPG
Fuel Economy Est-Combined N/A MPG
Cruising Range - Hwy 459.20 mi
EPA MPG Equivalent - City N/A
EPA MPG Equivalent - Hwy N/A
EPA MPG Equivalent - Combined N/A
Estimated Battery Range N/A mi
Drivetrain Front Wheel Drive
Trans Type 5
Trans Description Cont. Manual w/OD
Trans Description Cont. Again Not Available
First Gear Ratio (:1) 3.50
Second Gear Ratio (:1) 1.94
Third Gear Ratio (:1) 1.30
Fourth Gear Ratio (:1) 0.94
Fifth Gear Ratio (:1) 0.79
Reverse Ratio (:1) 3.44
Final Drive Axle Ratio (:1) 3.70
Suspension Type - Front Four-link
Suspension Type - Rear Independent
Suspension Type - Front (Cont.) Not Available
Suspension Type - Rear (Cont.) Torsion Beam
Brake Type Pwr
Brake ABS System 4-Wheel
Brake ABS System (Second Line) N/A
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 11.3 x 0.98 in
Rear Brake Rotor Diam x Thickness 9.6 x 0.39 in
Drum - Rear (Yes or ) Not Available
Fuel Tank Capacity, Approx 16.4 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Pwr Rack & Pinion
Steering Ratio (:1), Overall 14.3
Lock to Lock Turns (Steering) 2.8
Turning Diameter - Curb to Curb 37.4 ft
Turning Diameter - Wall to Wall N/A ft
Front Tire Size P205/55HR16
Rear Tire Size P205/55HR16
Spare Tire Size P205/55HR16
Dead Weight Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Trailer Wt. N/A lbs
Wt Distributing Hitch - Max Tongue Wt. N/A lbs
Base Curb Weight 3413 lbs
Passenger Capacity 5
Passenger Volume 92 ft³
Front Head Room 37.8 in
Front Leg Room 41.5 in
Front Shoulder Room 55.8 in
Front Hip Room N/A in
Second Head Room 37.3 in
Second Leg Room 35.3 in
Second Shoulder Room 54.6 in
Second Hip Room N/A in
Wheelbase 106.4 in
Length, Overall 185.2 in
Width, Max w/o mirrors 68.7 in
Height, Overall 57.6 in
Track Width, Front 59.6 in
Track Width, Rear 59.6 in
Min Ground Clearance 5.8 in
Liftover Height N/A in
Trunk Volume 15 ft³
Molded door trim in leatherette Optional
Independent torsion beam axle rear suspension Standard
Seat belt reminder & fuel cap seal warning Standard
(4) trunk tie-down hooks Standard
Genuine walnut wood interior trim Optional
Body-color pwr folding heated side mirrors w/memory, auto tilt-down in reversing, integrated turn signals Optional
Cruise control Standard
Fully carpet-lined luggage compartment w/light Standard
Daytime running lights Standard
Homelink Optional
Premium V AM/FM stereo w/cassette/CD player-inc: (8) speakers, Monsoon sound system Optional
Leather-wrapped 4-spoke tilt padded steering wheel w/height-adjustable/ telescopic steering column, cruise/audio controls Optional
16" x 7" alloy wheels w/anti-theft wheel locks Optional
Child safety locks on rear doors Standard
Rear outboard 3-point seat belts w/outboard pretensioners Standard
Audible/visible anti-theft vehicle alarm system-inc: doors, hood, trunk, radio, starter Standard
Daytime running lights Standard
Pwr 4-wheel disc brakes w/vented front Standard
Rear window defroster Standard
Body-color door handles Standard
Wood shift knob Optional
Front/rear gas shock absorbers Standard
Slidable folding front center armrest w/storage compartment Standard
Black grille w/center logo Standard
Electronic Differential Lock (EDL) Standard
Steel exhaust pipes Standard
Central pwr locking system-inc: automatic door locks, key-operated window open/close, selective unlocking at driver door, key-operated closing for pwr sunroof Optional
Valet key Standard
Front 3-point height-adjustable seat belts w/pretensioners Standard
Full-size spare wheel Standard
Front center dome light w/time delay Standard
(2) front/(2) rear reading lights Standard
Internal emergency release trunk handle w/location reflector Standard
Manual rear side sunshade Optional
Leather hand brake grip Optional
4-wheel anti-lock braking system (ABS) Standard
Anti-Slip Regulation (ASR) Standard
Dual-note horn Standard
Body-color body-side moldings Standard
Traction control-inc: Electronic Stabilization Program (ESP), brake assist Optional
Pwr tilt/slide sunroof-inc: tinted glass, sunshade, pinch protection, driver door pwr convenient closing Optional
Front/rear seat belt emergency tensioning retractors Standard
Instrumentation-inc: speedometer, odometer, trip odometer, tachometer, fuel/ temp gauges, gear indicator, warning lights, digital clock Standard
Headlights-on warning tone Standard
Mirror control pad w/joystick control Standard
Traction control-inc: Electronic Stabilization Program (ESP), brake assist Optional
City 20/hwy 28 (2.8L engine/5-speed manual trans) Standard
Child seat lower attachment points & top tether, rear outboard seating positions (LATCH) Standard
Fully reclining 8-way pwr leather heated front bucket seats w/driver-side 3-position memory, adjustable headrests, lumbar support Optional
Sun visor extention Optional
Gray-tinted upper windshield stripe Standard
Illuminated lockable glove box w/adjustable cooling feature Standard
2.8L DOHC SMPI 30-valve V6 engine Optional
Front seatback storage pockets Standard
Front/rear coil springs/stabilizer bars Standard
4-wheel anti-lock braking system (ABS) Standard
Front/rear passenger assist handles Standard
OnStar Telematics Optional
Interior ambient lights Optional
6-disc CD changer preparation-inc: wiring harness, mounting shelf in trunk Standard
Collapsible steering column Standard
Chrome loading edge protection Standard
Dual illuminated visor vanity mirrors w/covers Standard
Front door storage pockets w/rubber liners Standard
Full-size spare tire Standard
60/40 split folding rear seat-inc: adjustable headrests, fold-flat feature, folding center armrest w/storage compartment, cup holders Standard
Pwr windows-inc: driver-side 1-touch up/down & lockout features, pinch protection Standard
Rear heating/air conditioning ducts Standard
Immobilizer III theft-deterrent system Standard
P205/55HR16 all-season tires Optional
Body-color bumpers w/black lower section Standard
Rain sensing/speed-sensitive 2-speed aero windshield wipers w/4-speed adjustable intermittent wipe feature Optional
Self-dimming rearview mirror w/switch Optional
Anti-Slip Regulation (ASR) Standard
Driver/front passenger airbag supplemental restraint system Standard
Heated front windshield washer nozzles Optional
Pwr rack & pinion steering Standard
Integrated armrests in door panels Standard
Tinted green glass Standard
Multi-function trip computer-inc: trip time/length, average speed/fuel consumption, outside temp Standard
Pwr remote trunk/fuel door releases located on drivers door Standard
Rear seat interlock Standard
Front/rear side curtain protection Standard
Center console-inc: (2) cup holders Standard
Bumper-integrated front fog lamps Optional
(3) pwr outlets-inc: (1) in front center console, (1) in rear center console, (1) in cargo area Standard
Front wheel drive Standard
90-amp alternator Standard
Front four-link suspension Standard
5-speed manual transmission w/OD Standard
82 amp/hr battery Optional
16.4 gallon fuel tank Standard
Front/rear floor mats Standard
Driver/front passenger side-impact airbags Standard
Electronic climate control air conditioning w/pollen/dust filters Optional
