2004 Volkswagen Passat GLX specs & colors

$29,780
Starting MSRP
Current listing price
2004 Volkswagen Passat GLX

Showing the 2004 Volkswagen Passat 4dr Sdn GLX V6 Manual

Shop Now

Key specs

Color options

Interior

Slate Blue


Grey-Violet


Medium Prarie Tan


Medium Mocha


Mocha


Crystal Blue


Pumice


Cypress / Dark Cypress


Royal Blue


Gray


Black


Packages

Specifications

EPA Classification Mid-Size
Front Wheel Size 16 x 7 in
Rear Wheel Size 16 x 7 in
Spare Wheel Size 16 x 7 in
Front Wheel Material Alloy
Rear Wheel Material Alloy
Spare Wheel Material N/A
Cold Cranking Amps @ 0° F (Primary) N/A
Maximum Alternator Capacity (amps) 90
Engine Type Gas V6
Displacement 2.8L/169
SAE Net Horsepower @ RPM 190 @ 6000
SAE Net Torque @ RPM 206 @ 3200
EPA Fuel Economy Est - Hwy 28 MPG
Cruising Range - City 328.00 mi
EPA Fuel Economy Est - City 20 MPG
Fuel Economy Est-Combined N/A MPG
Cruising Range - Hwy 459.20 mi
EPA MPG Equivalent - City N/A
EPA MPG Equivalent - Hwy N/A
EPA MPG Equivalent - Combined N/A
Estimated Battery Range N/A mi
Drivetrain Front Wheel Drive
Trans Type 5
Trans Description Cont. Manual w/OD
Trans Description Cont. Again Not Available
First Gear Ratio (:1) 3.50
Second Gear Ratio (:1) 1.94
Third Gear Ratio (:1) 1.30
Fourth Gear Ratio (:1) 0.94
Fifth Gear Ratio (:1) 0.79
Reverse Ratio (:1) 3.44
Final Drive Axle Ratio (:1) 3.70
Suspension Type - Front Four-link
Suspension Type - Rear Independent
Suspension Type - Front (Cont.) Not Available
Suspension Type - Rear (Cont.) Torsion Beam
Brake Type Pwr
Brake ABS System 4-Wheel
Brake ABS System (Second Line) N/A
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 11.3 x 0.98 in
Rear Brake Rotor Diam x Thickness 9.6 x 0.39 in
Drum - Rear (Yes or ) Not Available
Fuel Tank Capacity, Approx 16.4 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Pwr Rack & Pinion
Steering Ratio (:1), Overall 14.3
Lock to Lock Turns (Steering) 2.8
Turning Diameter - Curb to Curb 37.4 ft
Turning Diameter - Wall to Wall N/A ft
Front Tire Size P205/55HR16
Rear Tire Size P205/55HR16
Spare Tire Size P205/55HR16
Dead Weight Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Trailer Wt. N/A lbs
Wt Distributing Hitch - Max Tongue Wt. N/A lbs
Base Curb Weight 3413 lbs
Passenger Capacity 5
Passenger Volume 92 ft³
Front Head Room 37.8 in
Front Leg Room 41.5 in
Front Shoulder Room 55.8 in
Front Hip Room N/A in
Second Head Room 37.3 in
Second Leg Room 35.3 in
Second Shoulder Room 54.6 in
Second Hip Room N/A in
Wheelbase 106.4 in
Length, Overall 185.2 in
Width, Max w/o mirrors 68.7 in
Height, Overall 57.6 in
Track Width, Front 59.6 in
Track Width, Rear 59.6 in
Min Ground Clearance 5.8 in
Liftover Height N/A in
Trunk Volume 15 ft³
Molded door trim in leatherette Optional
Independent torsion beam axle rear suspension Standard
Seat belt reminder & fuel cap seal warning Standard
(4) trunk tie-down hooks Standard
Genuine walnut wood interior trim Optional
Body-color pwr folding heated side mirrors w/memory, auto tilt-down in reversing, integrated turn signals Optional
Cruise control Standard
Fully carpet-lined luggage compartment w/light Standard
Daytime running lights Standard
Homelink Optional
Premium V AM/FM stereo w/cassette/CD player-inc: (8) speakers, Monsoon sound system Optional
Leather-wrapped 4-spoke tilt padded steering wheel w/height-adjustable/ telescopic steering column, cruise/audio controls Optional
16" x 7" alloy wheels w/anti-theft wheel locks Optional
Child safety locks on rear doors Standard
Rear outboard 3-point seat belts w/outboard pretensioners Standard
Audible/visible anti-theft vehicle alarm system-inc: doors, hood, trunk, radio, starter Standard
Daytime running lights Standard
Pwr 4-wheel disc brakes w/vented front Standard
Rear window defroster Standard
Body-color door handles Standard
Wood shift knob Optional
Front/rear gas shock absorbers Standard
Slidable folding front center armrest w/storage compartment Standard
Black grille w/center logo Standard
Electronic Differential Lock (EDL) Standard
Steel exhaust pipes Standard
Central pwr locking system-inc: automatic door locks, key-operated window open/close, selective unlocking at driver door, key-operated closing for pwr sunroof Optional
Valet key Standard
Front 3-point height-adjustable seat belts w/pretensioners Standard
Full-size spare wheel Standard
Front center dome light w/time delay Standard
(2) front/(2) rear reading lights Standard
Internal emergency release trunk handle w/location reflector Standard
Manual rear side sunshade Optional
Leather hand brake grip Optional
4-wheel anti-lock braking system (ABS) Standard
Anti-Slip Regulation (ASR) Standard
Dual-note horn Standard
Body-color body-side moldings Standard
Traction control-inc: Electronic Stabilization Program (ESP), brake assist Optional
Pwr tilt/slide sunroof-inc: tinted glass, sunshade, pinch protection, driver door pwr convenient closing Optional
Front/rear seat belt emergency tensioning retractors Standard
Instrumentation-inc: speedometer, odometer, trip odometer, tachometer, fuel/ temp gauges, gear indicator, warning lights, digital clock Standard
Headlights-on warning tone Standard
Mirror control pad w/joystick control Standard
Traction control-inc: Electronic Stabilization Program (ESP), brake assist Optional
City 20/hwy 28 (2.8L engine/5-speed manual trans) Standard
Child seat lower attachment points & top tether, rear outboard seating positions (LATCH) Standard
Fully reclining 8-way pwr leather heated front bucket seats w/driver-side 3-position memory, adjustable headrests, lumbar support Optional
Sun visor extention Optional
Gray-tinted upper windshield stripe Standard
Illuminated lockable glove box w/adjustable cooling feature Standard
2.8L DOHC SMPI 30-valve V6 engine Optional
Front seatback storage pockets Standard
Front/rear coil springs/stabilizer bars Standard
4-wheel anti-lock braking system (ABS) Standard
Front/rear passenger assist handles Standard
OnStar Telematics Optional
Interior ambient lights Optional
6-disc CD changer preparation-inc: wiring harness, mounting shelf in trunk Standard
Collapsible steering column Standard
Chrome loading edge protection Standard
Dual illuminated visor vanity mirrors w/covers Standard
Front door storage pockets w/rubber liners Standard
Full-size spare tire Standard
60/40 split folding rear seat-inc: adjustable headrests, fold-flat feature, folding center armrest w/storage compartment, cup holders Standard
Pwr windows-inc: driver-side 1-touch up/down & lockout features, pinch protection Standard
Rear heating/air conditioning ducts Standard
Immobilizer III theft-deterrent system Standard
P205/55HR16 all-season tires Optional
Body-color bumpers w/black lower section Standard
Rain sensing/speed-sensitive 2-speed aero windshield wipers w/4-speed adjustable intermittent wipe feature Optional
Self-dimming rearview mirror w/switch Optional
Anti-Slip Regulation (ASR) Standard
Driver/front passenger airbag supplemental restraint system Standard
Heated front windshield washer nozzles Optional
Pwr rack & pinion steering Standard
Integrated armrests in door panels Standard
Tinted green glass Standard
Multi-function trip computer-inc: trip time/length, average speed/fuel consumption, outside temp Standard
Pwr remote trunk/fuel door releases located on drivers door Standard
Rear seat interlock Standard
Front/rear side curtain protection Standard
Center console-inc: (2) cup holders Standard
Bumper-integrated front fog lamps Optional
(3) pwr outlets-inc: (1) in front center console, (1) in rear center console, (1) in cargo area Standard
Front wheel drive Standard
90-amp alternator Standard
Front four-link suspension Standard
5-speed manual transmission w/OD Standard
82 amp/hr battery Optional
16.4 gallon fuel tank Standard
Front/rear floor mats Standard
Driver/front passenger side-impact airbags Standard
Electronic climate control air conditioning w/pollen/dust filters Optional
