2005 Ford F-150 XLT specs & colors

Extended Cab Pickup

Change trim

$29,205

Starting MSRP
Current listing price

2005 Ford F-150 XLT

Showing the 2005 Ford F-150 Supercab Flareside 145" XLT

Shop Now

Key specs

2-door
5 seats
231.0-hp, 4.6-liter, 8 Cylinder Engine (Gasoline Fuel)
0 combined MPG
211.2" length, 75.6" height
Rear Wheel Drive

Color options

Exterior

Arizona Beige Metallic

Interior

Charcoal

Crystal Blue

Medium Tan

Packages

XLT SERIES ORDER CODE

$0

Starting MSRP

Specifications

Highlights

Engine Type: Gas V8
MPG: 15 City / 19 Hwy
Horsepower: 300 hp
231 hp
Seating Capacity: 5

Brakes

Brake Type: Power
Brake ABS System: 4-wheel
Brake ABS System (Second Line): Not Available
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness: 13.0 x 0.55 in
Rear Brake Rotor Diam x Thickness: 13.7 x 0.47 in
Drum - Rear (Yes or ): Not Available

Electrical

Cold Cranking Amps @ 0° F (Primary): 540
Maximum Alternator Capacity (amps): 130

Engine

Engine Type: Gas V8
Displacement: 4.6L/281
SAE Net Horsepower @ RPM: 231 @ 4750
SAE Net Torque @ RPM: 293 @ 3500
Transmission Options: A/T
4-Speed A/T
MPG: 15 City / 19 Hwy
Total Cooling System Capacity: 19.7 qts

Measurements

Front Leg Room: 41 in
Front Shoulder Room: 67 in
Front Hip Room: 66 in
Second Head Room: 40 in
Second Leg Room: 33 in
Second Shoulder Room: 67 in
Second Hip Room: 67 in
Wheelbase: 145 in
Length, Overall w/o rear bumper: 230 in
Length, Overall w/rear bumper: N/A
Length, Overall: N/A
Width, Max w/o mirrors: 79 in
Height, Overall: 73 in
Overhang, Front: 37 in
Cab to End of Frame: N/A
Ext'd Cab Cargo Volume: Not Available ft³
Cargo Volume: 59 ft³
Tailgate Width: 59 in
Cargo Box (Area) Height: 22 in
Cargo Box Width @ Wheelhousings: 50 in
Cargo Box Width @ Floor: 49 in
Cargo Box Width @ Top, Rear: 52 in
Cargo Box Length @ Floor: 79 in
Ground Clearance, Rear: N/A
Ground Clearance, Front: N/A
Passenger Capacity: 6
Overhang, Rear w/o bumper: 48 in
Front Head Room: 41 in
Ground to Top of Load Floor: 33 in

Steering

Steering Type: Pwr Rack & Pinion
Steering Ratio (:1), Overall: N/A
Turning Diameter - Curb to Curb: 46 ft
Turning Diameter - Wall to Wall: N/A

Suspension

Suspension Type - Front: Coil Spring
Suspension Type - Rear: Leaf Spring
Axle Type - Front: Double Wishbone
Axle Type - Rear: Semi-Floating

Tires & Wheels

Front Tire Size: P235/70R17
Rear Tire Size: P235/70R17
Spare Tire Size: P235/70R17
Front Wheel Size: 17 x 7.5 in
Rear Wheel Size: 17 x 7.5 in
Spare Wheel Size: 17 x 7.5 in
Front Wheel Material: Steel
Rear Wheel Material: Steel
Spare Wheel Material: Steel

Weight & Capacity

Gross Combined Wt Rating: 11,700 lbs
Dead Weight Hitch - Max Trailer Wt.: 5,000 lbs
Dead Weight Hitch - Max Tongue Wt.: 500 lbs
Wt Distributing Hitch - Max Trailer Wt.: 6,400 lbs
Wt Distributing Hitch - Max Tongue Wt.: 640 lbs
Fifth Wheel Hitch - Max Trailer Wt.: 6,400 lbs
Fifth Wheel Hitch - Max Tongue Wt.: 640 lbs
Maximum Trailering Capacity: N/A
Gross Vehicle Weight Rating: 6,700 lbs
Total Option Weight: 0 lbs
Curb Weight: 5,085 lbs
Gross Axle Weight Rating: 7,250 lbs
Base Curb Weight: N/A
Curb Weight - Front: 2,902 lbs
Curb Weight - Rear: 2,183 lbs
Option Weight - Front: 0 lbs
Option Weight - Rear: 0 lbs
As Spec'd Curb Weight: 5,085 lbs
As Spec'd Payload: 1,615 lbs
Maximum Payload Capacity: 1,615 lbs
Fuel Tank Capacity, Approx: 27 gal
Aux Fuel Tank Capacity, Approx: Not Available gal
