2014 Ford Fiesta ST specs & colors
4dr Car
Change trim
MSRP
- 4dr Sdn S $14,100
- 5dr HB S $14,600
- 4dr Sdn SE $15,580
- 5dr HB SE $16,080
- 4dr Sdn Titanium $18,300
- 5dr HB Titanium $18,800
- 5dr HB ST $21,400
Key specs
Color options
Interior
Charcoal
Gray
Packages
$1,995
Starting MSRP
- Heated Mirrors
$0
Starting MSRP
$115
Starting MSRP
- Factory Invoiced Accessory
- Cargo Net
- Foldable Soft Cargo Organizer
Specifications
| EPA Classification | Compact Cars |
| Front Wheel Size | 17 X 7 in |
| Rear Wheel Size | 17 X 7 in |
| Spare Wheel Size | Full-Size in |
| Front Wheel Material | Aluminum |
| Rear Wheel Material | Aluminum |
| Spare Wheel Material | Steel |
| Cold Cranking Amps @ 0° F (Primary) | 500 |
| Maximum Alternator Capacity (amps) | N/A |
| Engine Type | Intercooled Turbo Regular Unleaded I-4 |
| Displacement | 1.6 L/97 |
| SAE Net Horsepower @ RPM | 197 @ 6000 |
| SAE Net Torque @ RPM | 202 @ 4200 |
| EPA Fuel Economy Est - Hwy | 35 MPG |
| Cruising Range - City | 322.40 mi |
| EPA Fuel Economy Est - City | 26 MPG |
| Fuel Economy Est-Combined | 29 MPG |
| Cruising Range - Hwy | 434.00 mi |
| EPA MPG Equivalent - City | N/A |
| EPA MPG Equivalent - Hwy | N/A |
| Estimated Battery Range | N/A mi |
| Drivetrain | Front Wheel Drive |
| Trans Type | 6 |
| Trans Description Cont. | Manual w/OD |
| Trans Description Cont. Again | N/A |
| First Gear Ratio (:1) | 3.73 |
| Second Gear Ratio (:1) | 2.10 |
| Third Gear Ratio (:1) | 1.36 |
| Fourth Gear Ratio (:1) | 1.03 |
| Fifth Gear Ratio (:1) | 0.82 |
| Sixth Gear Ratio (:1) | 0.69 |
| Reverse Ratio (:1) | 3.73 |
| Final Drive Axle Ratio (:1) | 3.82 |
| Suspension Type - Front | Strut |
| Suspension Type - Rear | Torsion Beam |
| Suspension Type - Front (Cont.) | Strut |
| Suspension Type - Rear (Cont.) | Torsion Beam |
| Brake Type | 4-Wheel Disc |
| Brake ABS System | 4-Wheel |
| Brake ABS System (Second Line) | N/A |
| Disc - Front (Yes or ) | Yes |
| Disc - Rear (Yes or ) | Yes |
| Front Brake Rotor Diam x Thickness | 10.9 in |
| Rear Brake Rotor Diam x Thickness | 10 in |
| Drum - Rear (Yes or ) | N/A |
| Fuel Tank Capacity, Approx | 12.4 gal |
| Aux Fuel Tank Capacity, Approx | N/A gal |
| Steering Type | Rack-Pinion |
| Steering Ratio (:1), Overall | N/A |
| Lock to Lock Turns (Steering) | N/A |
| Turning Diameter - Curb to Curb | 35.5 ft |
| Turning Diameter - Wall to Wall | N/A ft |
| Front Tire Size | P205/40WR17 |
| Rear Tire Size | P205/40WR17 |
| Spare Tire Size | Full-Size |
| Dead Weight Hitch - Max Trailer Wt. | N/A lbs |
| Dead Weight Hitch - Max Tongue Wt. | N/A lbs |
| Wt Distributing Hitch - Max Trailer Wt. | N/A lbs |
| Wt Distributing Hitch - Max Tongue Wt. | N/A lbs |
| Base Curb Weight | 2720 lbs |
| Passenger Capacity | 5 |
| Passenger Volume | 85.1 ft³ |
| Front Head Room | 39.1 in |
| Front Leg Room | 42.2 in |
| Front Shoulder Room | 52.7 in |
| Front Hip Room | 50.6 in |
| Second Head Room | 37.2 in |
| Second Leg Room | 31.2 in |
| Second Shoulder Room | 49 in |
| Second Hip Room | 49.2 in |
| Wheelbase | 98 in |
| Length, Overall | 160.1 in |
| Width, Max w/o mirrors | 67.8 in |
| Height, Overall | 57.2 in |
| Track Width, Front | 57.7 in |
| Track Width, Rear | 57 in |
| Min Ground Clearance | N/A in |
| Liftover Height | N/A in |
| Cargo Volume with Rear Seat Up | 10.1 ft³ |
| Cargo Volume with Rear Seat Down | 26 ft³ |
| Trunk Volume | N/A ft³ |
| Automatic Equalizer | Standard |
| SYNC Communications & Entertainment System -inc: 911 Assist, VHR, traffic, directions and information services, redundant audio controls, floor center console w/USB and SYNC services (traffic reports, GPS based turn-by-turn directions and information services), SYNC services receive a complimentary 3 year prepaid subscription (one phone/primary account), Standard SYNC Services are available for a $60 annual subscription fee | Optional |
| Radio w/Seek-Scan, Clock, Speed Compensated Volume Control and Radio Data System | Standard |
| Radio: HD Sony AM/FM Stereo/CD Player/MP3 Capable -inc: input jack and SIRIUS satellite radio | Optional |
| Integrated Roof Antenna | Standard |
| Wireless Phone Connectivity | Standard |
| Turn-By-Turn Navigation Directions | Optional |
| Digital Signal Processor | Standard |
| Front Fog Lamps | Optional |
| Perimeter/Approach Lights | Optional |
| Body-Colored Door Handles | Standard |
| Rocker Panel Extensions | Optional |
| Body-Colored Front Bumper | Standard |
| Body-Colored Power Side Mirrors w/Convex Spotter, Manual Folding and Turn Signal Indicator | Optional |
| Tires: P205/40R17 W Summer Performance | Optional |
| Fixed Rear Window w/Fixed Interval Wiper, Heated Wiper Park and Defroster | Standard |
| Wing Spoiler | Optional |
| Body-Colored Rear Bumper w/Black Bumper Insert | Standard |
| Auto On/Off Reflector Halogen Daytime Running Headlamps w/Delay-Off | Optional |
| Liftgate Rear Cargo Access | Standard |
| Fully Galvanized Steel Panels | Standard |
| Chrome Grille | Standard |
| Full-Size Spare Tire Mounted Inside Under Cargo | Optional |
| Black Side Windows Trim and Black Front Windshield Trim | Standard |
| Steel Spare Wheel | Standard |
| Variable Intermittent Wipers | Standard |
| Tailgate/Rear Door Lock Included w/Power Door Locks | Standard |
| Wheels: 17" Alloy | Optional |
| Light Tinted Glass | Standard |
| Front Center Armrest | Optional |
| Proximity Key For Doors And Push Button Start | Optional |
| Unique Cloth Front Sport Bucket Seats -inc: ST logo, 6-way manual (fore/aft, up/down, recline) driver seats, 4-way manual (fore/aft, recline) passenger seats, 2-way adjustable headrests | Optional |
| HVAC -inc: Underseat Ducts | Standard |
| Automatic Air Conditioning | Optional |
| Cloth Door Trim Insert | Standard |
| Rigid Cargo Cover | Standard |
| Driver Information Center | Optional |
| Manual Adjustable Rear Head Restraints | Standard |
| Remote Keyless Entry w/Integrated Key Transmitter and Illuminated Entry | Optional |
| Leather/Metal-Look Gear Shifter Material | Optional |
| Outside Temp Gauge | Optional |
| Air Filtration | Standard |
| Passenger Seat | Standard |
| 60-40 Folding Bench Front Facing Fold Forward Seatback Premium Cloth Rear Seat | Optional |
| Full Floor Console w/Storage, Mini Overhead Console w/Storage and 2 12V DC Power Outlets | Optional |
| Instrument Panel Bin, Driver And Passenger Door Bins | Standard |
| Illuminated Glove Box | Standard |
| Front And Rear Map Lights | Optional |
| Cargo Space Lights | Standard |
| Cargo Area Concealed Storage | Standard |
| Trip Computer | Optional |
| Compass | Optional |
| Full Carpet Floor Covering -inc: Carpet Front And Rear Floor Mats | Optional |
| Driver Seat | Standard |
| Front Cupholder | Standard |
| Analog Appearance | Standard |
| 2 12V DC Power Outlets | Optional |
| Perimeter Alarm | Optional |
| Securilock Anti-Theft Ignition (pats) Immobilizer | Standard |
| Carpet Floor Trim | Standard |
| Seats w/Cloth Back Material | Standard |
| Leather/Metal-Look Steering Wheel | Optional |
| Interior Trim -inc: Piano Black Instrument Panel Insert and Aluminum/Metal-Look Interior Accents | Optional |
| Gauges -inc: Speedometer, Odometer, Tachometer, Trip Odometer and Trip Computer | Optional |
| Cruise Control w/Steering Wheel Controls | Optional |
| Full Cloth Headliner | Standard |
| Driver Foot Rest | Standard |
| Power Rear Windows and Fixed 3rd Row Windows | Optional |
| Power 1st Row Windows w/Driver 1-Touch Up/Down | Optional |
| Selective Service Internet Access | Standard |
| MyFord Touch -inc: 6.5" color touch screen in center-stack, media hub w/USB Ports (2), SD Card Reader and RCA | Optional |
| Power Door Locks w/Autolock Feature | Standard |
| FOB Controls -inc: Cargo Access | Optional |
| Day-Night Rearview Mirror | Standard |
| Manual Tilt/Telescoping Steering Column | Standard |
| Driver And Passenger Visor Vanity Mirrors | Standard |
| Rear Cupholder | Standard |
| 1 Seatback Storage Pocket | Standard |
| Fade-To-Off Interior Lighting | Standard |
| Front-Wheel Drive | Standard |
| Torsion Beam Rear Suspension w/Coil Springs | Standard |
| Strut Front Suspension w/Coil Springs | Standard |
| Electric Power-Assist Speed-Sensing Steering | Standard |
| Gas-Pressurized Shock Absorbers | Standard |
| 3.82 Axle Ratio | Optional |
| Transmission: 6-Speed Manual (STD) | Optional |
| 500CCA Maintenance-Free Battery w/Run Down Protection | Standard |
| Front Anti-Roll Bar | Standard |
| 4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs and Hill Hold Control | Optional |
| 50-State Emissions System | Optional |
| Engine: 1.6L GTDI EcoBoost (STD) | Optional |
| Brake Actuated Limited Slip Differential | Optional |
| Single Stainless Steel Exhaust w/Chrome Tailpipe Finisher | Optional |
| 12.4 Gal. Fuel Tank | Standard |
| Sport Tuned Suspension | Optional |
| AdvanceTrac Electronic Stability Control (ESC) | Standard |
| Driver Knee Airbag | Standard |
| Airbag Occupancy Sensor | Standard |
| Dual Stage Driver And Passenger Seat-Mounted Side Airbags | Standard |
| Curtain 1st And 2nd Row Airbags | Standard |
| Low Tire Pressure Warning | Standard |
| Dual Stage Driver And Passenger Front Airbags | Standard |
| Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners | Standard |
| Mykey System -inc: Top Speed Limiter, Audio Volume Limiter, Early Low Fuel Warning, Programmable Sound Chimes and Beltminder w/Audio Mute | Optional |
| Side Impact Beams | Standard |
| Rear Child Safety Locks | Standard |
| ABS And Driveline Traction Control | Standard |
