2019 Ford Ranger LARIAT specs & colors

$38,565
Starting MSRP
Current listing price
2019 Ford Ranger LARIAT

Showing the 2019 Ford Ranger LARIAT 4WD SuperCrew 5' Box

Shop Now

Key specs

Color options

Interior

Linen Beige


Dk / Lt Slate Gray


Packages

$795

Starting MSRP

  • Adaptive Cruise Control
  • Navigation,

$795

Starting MSRP

  • Chrome Door & Tailgate Handles
  • Chrome Front & Rear Bumpers
  • Chrome Exhaust Tip

Chrome Appearance Package

$1,295

Starting MSRP

  • exposed steel bash plate and remove front air dam
  • Terrain Management System
  • Trail Control

FX4 Off-Road Package

See all packages

$495

Starting MSRP

  • towing capability up to 7500 lbs and 4-pin/7-pin wiring harness
  • Class IV Trailer Hitch Receiver,

$895

Starting MSRP

  • Sport Box Decal
  • Wheels: 17" Magnetic Painted Aluminum
  • Black Grille w/Magnetic Surround & Bars

Sport Appearance Package

$0

Starting MSRP

$1,995

Starting MSRP

  • black sill plates
  • Black Grille w/Black Surround & Black Bars
  • Black Mirror Skull Caps

Black Appearance Package

$1,795

Starting MSRP

  • Rain-Sensing Wipers
  • Remote Start
  • Technology Package

Equipment Group 501A Mid

$395

Starting MSRP

  • Plastic Drop-In Bedliner
  • 12V Power Plug

Specifications

Front Wheel Size 18 X 8 in
Rear Wheel Size 18 X 8 in
Spare Wheel Size Full-Size in
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 150
Engine Type Intercooled Turbo Regular Unleaded I-4
Displacement 2.3 L/140
SAE Net Horsepower @ RPM 270 @ 5500
SAE Net Torque @ RPM 310 @ 3000
Engine Oil Cooler None
EPA Fuel Economy Est - Hwy 24 MPG
Cruising Range - City 360.00 mi
EPA Fuel Economy Est - City 20 MPG
Fuel Economy Est-Combined 22 MPG
Cruising Range - Hwy 432.00 mi
Estimated Battery Range N/A mi
Drivetrain Four Wheel Drive
Trans Type 10
Trans Description Cont. Automatic w/OD
Trans Description Cont. Again N/A
First Gear Ratio (:1) 4.70
Second Gear Ratio (:1) 2.98
Third Gear Ratio (:1) 2.15
Fourth Gear Ratio (:1) 1.77
Fifth Gear Ratio (:1) 1.52
Sixth Gear Ratio (:1) 1.27
Reverse Ratio (:1) 4.87
Trans Power Take Off N/A
Final Drive Axle Ratio (:1) N/A
Transfer Case Model Electronic
Transfer Case Gear Ratio (:1), High N/A
Transfer Case Gear Ratio (:1), Low N/A
Transfer Case Power Take Off No
Seventh Gear Ratio (:1) 1.00
Eighth Gear Ratio (:1) 0.85
Ninth Gear Ratio (:1) N/A
Tenth Gear Ratio (:1) N/A
Suspension Type - Front Short And Long Arm
Suspension Type - Rear Leaf
Axle Type - Front Independent
Axle Type - Rear Rigid Axle
Frame Type N/A
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Brake ABS System (Second Line) 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12.2 in
Rear Brake Rotor Diam x Thickness 12.1 in
Drum - Rear (Yes or ) N/A
Fuel Tank Capacity, Approx 18 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Rack-Pinion
Steering Ratio (:1), Overall N/A
Turning Diameter - Curb to Curb 42 ft
Turning Diameter - Wall to Wall N/A ft
Front Tire Size P265/60SR18
Rear Tire Size P265/60SR18
Spare Tire Size Full-Size
Dead Weight Hitch - Max Trailer Wt. 3500 lbs
Dead Weight Hitch - Max Tongue Wt. 350 lbs
Wt Distributing Hitch - Max Trailer Wt. 3500 lbs
Wt Distributing Hitch - Max Tongue Wt. 350 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Maximum Trailering Capacity 3500 lbs
Base Curb Weight 4441 lbs
Curb Weight - Front 2554 lbs
Curb Weight - Rear 1887 lbs
Option Weight - Front 0.00 lbs
Option Weight - Rear 0.00 lbs
As Spec'd Curb Weight 4441.00 lbs
As Spec'd Payload 1609.00 lbs
Maximum Payload Capacity 1609.00 lbs
Gross Combined Wt Rating 9000 lbs
Gross Axle Weight Rating 6500.00 lbs
Curb Weight 4441.00 lbs
Total Option Weight 0.00 lbs
Gross Vehicle Weight Rating 6050.00 lbs
Passenger Capacity 5
Front Head Room 41 in
Front Leg Room 43.1 in
Front Shoulder Room 56.7 in
Front Hip Room 55.8 in
Second Head Room 38.3 in
Second Leg Room 34.5 in
Second Shoulder Room 56.3 in
Second Hip Room 53.5 in
Wheelbase 126.8 in
Length, Overall w/o rear bumper N/A in
Length, Overall w/rear bumper N/A in
Length, Overall 210.8 in
Width, Max w/o mirrors 85.8 in
Height, Overall 71.5 in
Overhang, Front 35.8 in
Overhang, Rear w/o bumper N/A in
Cab to End of Frame N/A in
Ground to Top of Load Floor 33.8 in
Ground Clearance, Front 8.9 in
Ground Clearance, Rear 8.9 in
Cargo Box Length @ Floor 60 in
Cargo Box Width @ Top, Rear 61.4 in
Cargo Box Width @ Floor 61.4 in
Cargo Box Width @ Wheelhousings 44.8 in
Cargo Box (Area) Height 20.9 in
Tailgate Width 55.4 in
Cargo Volume 43.3 ft³
Ext'd Cab Cargo Volume N/A ft³
SiriusXM Satellite Radio -inc: a 6-month prepaid subscription, Service is not available in Alaska and Hawaii, Subscriptions to all SiriusXM services are sold by SiriusXM after trial period, If you decide to continue service after your trial, the subscription plan you choose will automatically renew thereafter and you will be charged according to your chosen payment method at then-current rates, Fees and taxes apply, To cancel you must call SiriusXM at 1-866-635-2349, See SiriusXM customer agreement for complete terms at www.siriusxm.com, All fees and programming subject to change, Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc Optional
Radio: AM/FM Stereo w/6 Speakers Optional
Integrated Roof Antenna Standard
Radio w/Seek-Scan and Speed Compensated Volume Control Standard
Body-Colored Rear Step Bumper Optional
Tailgate Rear Cargo Access Standard
Cargo Lamp w/High Mount Stop Light Standard
Front Fog Lamps Optional
Headlights-Automatic Highbeams Optional
Body-Colored Power Heated Side Mirrors w/Convex Spotter, Power Folding and Turn Signal Indicator Optional
Variable Intermittent Wipers Standard
Perimeter/Approach Lights Optional
Tailgate/Rear Door Lock Included w/Power Door Locks Optional
Body-Colored Door Handles Optional
Sliding Rear Window w/Defroster Optional
Tires: P265/60R18 A/T BSW (STD) Optional
Black Side Windows Trim and Black Front Windshield Trim Standard
Steel Spare Wheel Standard
Full-Size Spare Tire Stored Underbody w/Crankdown Standard
Autolamp Auto On/Off Projector Beam Led Low/High Beam Auto High-Beam Daytime Running Lights Preference Setting Headlamps w/Delay-Off Optional
Chrome Grille Optional
Body-Colored Wheel Well Trim Optional
Deep Tinted Glass Optional
Body-Colored Front Bumper w/Body-Colored Rub Strip/Fascia Accent and 2 Tow Hooks Optional
Wheels: 18" Machined Alum w/Stealth Gray Pockets (STD) Optional
Galvanized Steel/Aluminum Panels Standard
LED Brakelights Optional
Regular Box Style Standard
Fade-To-Off Interior Lighting Standard
Manual Tilt/Telescoping Steering Column Standard
Leather Gear Shifter Material Optional
Illuminated Locking Glove Box Optional
Leather/Metal-Look Steering Wheel Optional
Full Carpet Floor Covering -inc: Carpet Front And Rear Floor Mats Optional
FordPass Connect 4G LTE WiFi Mobile Hotspot Internet Access Optional
Perimeter Alarm Optional
Front And Rear Map Lights Optional
Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp, Inclinometer, Transmission Fluid Temp, Trip Odometer and Trip Computer Optional
Driver Information Center Optional
Manual w/Tilt Front Head Restraints and Manual Adjustable Rear Head Restraints Standard
Trip Computer Standard
FOB Controls -inc: Cargo Access Optional
Front Heated Leather-Trimmed Bucket Seats -inc: power 8-way adjustable driver/passenger w/power lumbar, flow-through console and floor shift Optional
Pickup Cargo Box Lights Standard
SYNC 3 -inc: enhanced voice recognition communications and entertainment system, 8" LCD touchscreen in center stack w/swipe capability, pinch-to-zoom capability included w/available voice-activated touchscreen navigation system, 911 Assist, Apple CarPlay, Android Auto and 2 smart-charging USB ports, Note: SYNC AppLink lets you control some of your favorite compatible mobile apps w/your voice, It is compatible w/select smartphone platforms, Commands may vary by phone and AppLink software Optional
Full Cloth Headliner Standard
Cruise Control w/Steering Wheel Controls Optional
Leather Door Trim Insert Optional
Compass Standard
Digital/Analog Appearance Optional
Front Center Armrest and Rear Center Armrest Standard
Full Overhead Console w/Storage, 3 12V DC Power Outlets and 1 120V AC Power Outlet Optional
Securilock Anti-Theft Ignition (pats) Immobilizer Standard
3 12V DC Power Outlets Standard
Outside Temp Gauge Optional
Power Rear Windows Optional
HVAC -inc: Underseat Ducts Standard
Full Folding Bench Front Facing Fold-Up Cushion Rear Seat Standard
Driver Seat Standard
Rear Cupholder Standard
Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button Optional
1 Seatback Storage Pocket Optional
Power Door Locks w/Autolock Feature Optional
Day-Night Auto-Dimming Rearview Mirror Optional
Interior Trim -inc: Piano Black Instrument Panel Insert, Cabback Insulator and Chrome Interior Accents Optional
Instrument Panel Bin, Dashboard Storage, Driver / Passenger And Rear Door Bins and 2nd Row Underseat Storage Standard
3 12V DC Power Outlets and 1 120V AC Power Outlet Optional
Front Cupholder Standard
Driver And Passenger Visor Vanity Mirrors w/Driver And Passenger Illumination Optional
Passenger Seat Standard
Garage Door Transmitter Optional
Power 1st Row Windows w/Driver 1-Touch Up/Down Optional
Redundant Digital Speedometer Optional
Smart Device Remote Engine Start Optional
Voice Activated Dual Zone Front Automatic Air Conditioning Optional
Proximity Key For Doors And Push Button Start Optional
Single Stainless Steel Exhaust Standard
Part-Time Four-Wheel Drive Standard
50-State Emissions System Standard
Transmission w/Driver Selectable Mode and SelectShift Sequential Shift Control Standard
TBD Axle Ratio (STD) Standard
Gas-Pressurized Shock Absorbers Standard
Solid Axle Rear Suspension w/Leaf Springs Standard
1560# Maximum Payload Standard
80-Amp/Hr 800CCA Maintenance-Free Battery w/Run Down Protection Optional
Short And Long Arm Front Suspension w/Coil Springs Standard
GVWR: 6,050 lbs Standard
18 Gal. Fuel Tank Standard
Front Anti-Roll Bar Standard
Auto Locking Hubs Standard
Engine: 2.3L EcoBoost -inc: auto start-stop technology (STD) Standard
4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs, Brake Assist and Hill Hold Control Standard
Transmission: Electronic 10-Speed SelectShift Auto (STD) Standard
Towing Equipment -inc: Trailer Sway Control Standard
Electronic Transfer Case Standard
150 Amp Alternator Standard
Electric Power-Assist Speed-Sensing Steering Standard
Trailer Wiring Harness Standard
Dual Stage Driver And Passenger Seat-Mounted Side Airbags Standard
Front And Rear Parking Sensors Optional
Rear Child Safety Locks Standard
Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners Standard
ABS And Driveline Traction Control Standard
Collision Warning-Front Standard
Dual Stage Driver And Passenger Front Airbags Standard
Back-Up Camera Standard
Collision Mitigation-Front Standard
Ford Co-Pilot360 - Pre-Collision Assist with Automatic Emergency Braking (AEB) and Cross Traffic Alert Optional
Safety Canopy System Curtain 1st And 2nd Row Airbags Standard
Ford Co-Pilot360 - Blind Spot Information System (BLIS) Blind Spot Optional
Tire Specific Low Tire Pressure Warning Standard
AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC) Standard
Airbag Occupancy Sensor Standard
Ford Co-Pilot360 - Lane-Keeping Assist Lane Keeping Assist Optional
Mykey System -inc: Top Speed Limiter, Audio Volume Limiter, Early Low Fuel Warning, Programmable Sound Chimes and Beltminder w/Audio Mute Optional
Side Impact Beams Standard
Ford Co-Pilot360 - Lane-Keeping Assist Lane Departure Warning Optional
