2017 Honda Ridgeline RTS specs & colors

$33,415
Starting MSRP
Current listing price

Showing the 2017 Honda Ridgeline RTS 4x4 Crew Cab 5.3' Bed

Shop Now

Key specs

Color options

Interior

Vanilla / Blue


Ecru / Royal Blue


Beige


Packages

$258

Starting MSRP

  • Wheel Locks
  • In-Bed Trunk Carpet
  • Rear Splash Guard

In-Bed Trunk Carpet Protection Package

$4,619

Starting MSRP

  • Black Roof Rails for Crossbars
  • Wheels: 18" Machined Finish Alloy
  • Sport Grille

Adventure Package

$311

Starting MSRP

  • Wheel Locks
  • All Season Floor Mats
  • In-Bed Trunk Carpet
See all packages

$340

Starting MSRP

  • All Season Floor Mats
  • In-Bed Trunk Carpet
  • Rear Splash Guard

All Season HW Protection Package I

$263

Starting MSRP

  • Wheel Locks
  • Rear Splash Guard
  • In-Bed Trunk Cargo Dividers

In-Bed Trunk Dividers Protection Package

Specifications

Front Wheel Material Aluminum
Spare Wheel Size Compact in
Front Wheel Size 18 X 7.5 in
Rear Wheel Size 18 X 7.5 in
Spare Wheel Material Steel
Rear Wheel Material Aluminum

Maximum Alternator Capacity (amps) N/A
Cold Cranking Amps @ 0° F (Primary) N/A

Engine Oil Cooler None
Engine Type Regular Unleaded V-6
SAE Net Horsepower @ RPM 280 @ 6000
SAE Net Torque @ RPM 262 @ 4700
Displacement 3.5 L/212

Fuel Economy Est-Combined 21 MPG
Cruising Range - City 351.00 mi
EPA Fuel Economy Est - City 18 MPG
Estimated Battery Range N/A mi
EPA Fuel Economy Est - Hwy 25 MPG
Cruising Range - Hwy 487.50 mi

Second Gear Ratio (:1) 2.10
Trans Power Take Off N/A
Transfer Case Gear Ratio (:1), High N/A
Trans Description Cont. Automatic w/OD
Reverse Ratio (:1) 2.27
Trans Description Cont. Again N/A
Transfer Case Gear Ratio (:1), Low N/A
Sixth Gear Ratio (:1) 0.56
Fourth Gear Ratio (:1) 1.06
First Gear Ratio (:1) 3.36
Transfer Case Model None
Trans Type 6
Drivetrain All Wheel Drive
Final Drive Axle Ratio (:1) N/A
Transfer Case Power Take Off No
Fifth Gear Ratio (:1) 0.75
Third Gear Ratio (:1) 1.49

Axle Type - Rear Independent
Suspension Type - Rear Multi-Link
Suspension Type - Front Strut
Axle Type - Front Independent

Frame Type N/A

Disc - Front (Yes or ) Yes
Brake ABS System (Second Line) 4-Wheel
Brake ABS System 4-Wheel
Drum - Rear (Yes or ) N/A
Brake Type 4-Wheel Disc
Rear Brake Rotor Diam x Thickness 13 in
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12.6 in

Fuel Tank Capacity, Approx 19.5 gal
Aux Fuel Tank Capacity, Approx N/A gal

Turning Diameter - Curb to Curb 44.4 ft
Steering Ratio (:1), Overall N/A
Steering Type Rack-Pinion
Turning Diameter - Wall to Wall N/A ft

Spare Tire Size Compact
Front Tire Size P245/60HR18
Rear Tire Size P245/60HR18

Maximum Trailering Capacity 5000 lbs
Wt Distributing Hitch - Max Trailer Wt. 5000 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Wt Distributing Hitch - Max Tongue Wt. 500 lbs
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs

Gross Axle Weight Rating N/A lbs
Option Weight - Front 0.00 lbs
Curb Weight - Rear N/A lbs
Gross Combined Wt Rating 9986 lbs
Curb Weight N/A lbs
Base Curb Weight 4433 lbs
Option Weight - Rear 0.00 lbs
Curb Weight - Front N/A lbs
As Spec'd Payload N/A lbs
Maximum Payload Capacity N/A lbs
As Spec'd Curb Weight N/A lbs
Total Option Weight 0.00 lbs
Gross Vehicle Weight Rating 6019.00 lbs

Cab to End of Frame N/A in
Passenger Capacity 5
Height, Overall 70.8 in
Wheelbase 125.2 in
Second Head Room 38.8 in
Front Head Room 40.1 in
Ground Clearance, Front 7.9 in
Ext'd Cab Cargo Volume N/A ft³
Length, Overall w/rear bumper N/A in
Length, Overall 210 in
Ground to Top of Load Floor N/A in
Width, Max w/o mirrors 78.6 in
Ground Clearance, Rear 7.9 in
Cargo Box Width @ Floor 60 in
Cargo Box Width @ Top, Rear 60 in
Cargo Box (Area) Height 16.7 in
Second Leg Room 36.7 in
Cargo Box Width @ Wheelhousings 50 in
Front Shoulder Room 62 in
Front Hip Room 59.1 in
Second Shoulder Room 61.5 in
Tailgate Width 51 in
Length, Overall w/o rear bumper N/A in
Front Leg Room 40.9 in
Overhang, Front N/A in
Overhang, Rear w/o bumper N/A in
Second Hip Room 56.6 in
Cargo Box Length @ Floor 64 in
Cargo Volume 33.9 ft³

Bluetooth Handsfreelink Wireless Phone Connectivity Standard
Audio Theft Deterrent Standard
Radio: AM/FM/MP3 -inc: 200-watts, Audio system w/7 speakers including subwoofer, Radio Data System (RDS), speed-sensitive volume control (SVC), auxiliary input jack, 1.0-amp charging port in center console and Bluetooth streaming audio, Bluetooth HandsFreeLink Standard
Integrated Roof Antenna Standard
2 LCD Monitors In The Front Standard
Radio w/Seek-Scan, Clock, Steering Wheel Controls, Voice Activation and External Memory Control Standard

Black Side Windows Trim, Black Front Windshield Trim and Black Rear Window Trim Standard
Body-Colored Power Side Mirrors w/Manual Folding Optional
Variable Intermittent Wipers Standard
Fully Galvanized Steel Panels Standard
Cargo Lamp w/High Mount Stop Light Standard
Body-Colored Front Bumper w/1 Tow Hook Standard
Regular Composite Box Style Standard
Deep Tinted Glass Standard
Integrated Storage Standard
Body-Colored Rear Step Bumper Standard
Fixed Rear Window w/Defroster Standard
Steel Spare Wheel Standard
Grille w/Chrome Bar Standard
Compact Spare Tire w/Box Carrier Standard
LED Brakelights Standard
Tires: P245/60R18 105H AS Standard
Body-Colored Door Handles Optional
Tailgate w/Swing-Out Rear Cargo Access Standard
Auto On/Off Projector Beam Halogen Daytime Running Headlamps w/Delay-Off Standard
Tailgate/Rear Door Lock Included w/Power Door Locks Standard
Wheels: 18" Machine-Finished Alloy Optional
Front Fog Lamps Optional

6-Way Driver Seat -inc: Manual Recline, Height Adjustment and Fore/Aft Movement Standard
Power Rear Windows Standard
Metal-Look Gear Shifter Material Standard
60-40 Folding Split-Bench Front Facing Fold-Up Cushion Rear Seat Standard
Valet Function Standard
Remote Keyless Entry w/Integrated Key Transmitter, 4 Door Curb/Courtesy, Illuminated Entry, Illuminated Ignition Switch and Panic Button Standard
Partial Floor Console w/Covered Storage, Mini Overhead Console w/Storage, Conversation Mirror and 3 12V DC Power Outlets Standard
Gauges -inc: Speedometer, Odometer, Engine Coolant Temp, Tachometer, Trip Odometer and Trip Computer Standard
Illuminated Locking Glove Box Standard
Air Filtration Standard
HomeLink Garage Door Transmitter Optional
Trip Computer Standard
Driver And Passenger Visor Vanity Mirrors Standard
FOB Controls -inc: Windows and Remote Start Standard
Immobilizer Standard
Outside Temp Gauge Optional
Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down Standard
Manual Adjustable Front Head Restraints and Manual Adjustable Rear Head Restraints Standard
Interior Trim -inc: Metal-Look Instrument Panel Insert, Metal-Look Door Panel Insert, Metal-Look Console Insert and Metal-Look Interior Accents Standard
Day-Night Rearview Mirror Standard
Front Bucket Seats Standard
Cloth Seat Trim Standard
Redundant Digital Speedometer Standard
Front And Rear Map Lights Standard
Rear HVAC w/Separate Controls Optional
Driver Foot Rest Standard
Full Carpet Floor Covering -inc: Carpet Front And Rear Floor Mats Standard
HVAC -inc: Underseat Ducts and Console Ducts Standard
Front Cupholder Standard
Power Door Locks w/Autolock Feature Standard
Manual Tilt/Telescoping Steering Column Standard
Remote Releases -Inc: Mechanical Fuel Standard
4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement Standard
Driver Information Center Standard
Full Cloth Headliner Standard
3 12V DC Power Outlets Standard
Proximity Key For Doors And Push Button Start Optional
Rear Cupholder Standard
Instrument Panel Covered Bin, Dashboard Storage, Driver And Passenger Door Bins, 2nd Row Underseat Storage and Audio Media Storage Standard
Cruise Control w/Steering Wheel Controls Standard
Pickup Cargo Box Lights Standard
Perimeter Alarm Standard
Driver And Front Passenger Armrests and Rear Center Armrest w/Storage Standard
Dual Zone Front Automatic Air Conditioning Optional
Analog Appearance Standard
2 Seatback Storage Pockets Optional
Fade-To-Off Interior Lighting Standard

Brake Actuated Limited Slip Differential Standard
Single Stainless Steel Exhaust Standard
Electric Power-Assist Speed-Sensing Steering Standard
4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs, Brake Assist and Hill Hold Control Standard
Engine: 3.5L 24V SOHC i-VTEC V6 Standard
Strut Front Suspension w/Coil Springs Standard
Transmission: 6-Speed Automatic Standard
Permanent Locking Hubs Standard
Multi-Link Rear Suspension w/Coil Springs Standard
Class III Towing Equipment -inc: Hitch and Trailer Sway Control Standard
4.25 Axle Ratio Standard
Transmission w/Driver Selectable Mode and HD Oil Cooler Standard
Automatic Full-Time All-Wheel Standard
19.5 Gal. Fuel Tank Standard
1580# Maximum Payload Optional
Gas-Pressurized Shock Absorbers Standard
Front And Rear Anti-Roll Bars Standard
1 Skid Plate Standard
Battery w/Run Down Protection Standard
GVWR: 6,019 lbs Standard
Trailer Wiring Harness Standard

Side Impact Beams Standard
ABS And Driveline Traction Control Standard
Curtain 1st And 2nd Row Airbags Standard
Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners Standard
Airbag Occupancy Sensor Standard
Back-Up Camera Standard
Dual Stage Driver And Passenger Seat-Mounted Side Airbags Standard
Tire Specific Low Tire Pressure Warning Standard
HondaLink Emergency Sos Standard
Dual Stage Driver And Passenger Front Airbags Standard
VSA Electronic Stability Control (ESC) Standard
Rear Child Safety Locks Standard
