2016 Chevrolet Silverado 1500 LS specs & colors

Crew Cab Pickup

Change trim

MSRP
Change trim
$41,990
Starting MSRP
Current listing price
2016 Chevrolet Silverado 1500 LS

Showing the 2016 Chevrolet Silverado 1500 4WD Crew Cab 153.0" LS

Shop Now

Key specs

Color options

Interior

Jet Black / Dark Ash

Jet Black

Packages

$0

Starting MSRP

  • includes standard equipment

$250

Starting MSRP

  • includes (VAV) all-weather floor mats
  • and (VBR) rubber bed mat

$295

Starting MSRP

  • includes (VQY) chrome recovery hooks
  • LPO and (VQZ) polished exhaust tip
  • LPO
See all packages

$795

Starting MSRP

  • includes (CGN) spray-on bedliner
  • (CTD) upper cargo tie downs and (SIE) Cross rails tiered storage system
  • LPO

$995

Starting MSRP

  • includes (VZX) Bedliner
  • LPO
  • (5JY) tonneau cover

LPO, Bed Protection Package

$995

Starting MSRP

  • includes (VZX) Bedliner
  • LPO
  • (5JY) tonneau cover
  • Soft cloth
  • folding
  • LPO and (CTD) upper tie downs,

Specifications

Front Wheel Size 17 x 8.0 in
Rear Wheel Size 17 x 8.0 in
Spare Wheel Size 17 x -TBD- in
Front Wheel Material Steel
Rear Wheel Material Steel
Spare Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) 720
Maximum Alternator Capacity (amps) 150
Engine Type Gas V8
Displacement 5.3L/325
SAE Net Horsepower @ RPM 355 @ 5600
SAE Net Torque @ RPM 383 @ 4100
Engine Oil Cooler Yes
EPA Fuel Economy Est - Hwy 22 MPG
Cruising Range - City 416.00 mi
EPA Fuel Economy Est - City 16 MPG
Fuel Economy Est-Combined 18 MPG
Cruising Range - Hwy 572.00 mi
Estimated Battery Range N/A mi
Drivetrain Four Wheel Drive
Trans Type 6
Trans Description Cont. Automatic
Trans Description Cont. Again N/A
First Gear Ratio (:1) 4.03
Second Gear Ratio (:1) 2.36
Third Gear Ratio (:1) 1.53
Fourth Gear Ratio (:1) 1.15
Fifth Gear Ratio (:1) 0.85
Sixth Gear Ratio (:1) 0.67
Reverse Ratio (:1) 3.06
Trans Power Take Off N/A
Final Drive Axle Ratio (:1) N/A
Transfer Case Model Magna MP1222/5/6
Transfer Case Gear Ratio (:1), High 1.00
Transfer Case Gear Ratio (:1), Low 2.72
Transfer Case Power Take Off N/A
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Axle Type - Front N/A
Axle Type - Rear N/A
Frame Type Hydroformed
Brake Type Pwr
Brake ABS System 4-Wheel
Brake ABS System (Second Line) N/A
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.0 x 1.18 in
Rear Brake Rotor Diam x Thickness 13.6 x 0.79 in
Drum - Rear (Yes or ) N/A
Fuel Tank Capacity, Approx 26 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Electric Rack & Pinion
Steering Ratio (:1), Overall N/A
Turning Diameter - Curb to Curb 48.6 ft
Turning Diameter - Wall to Wall N/A ft
Front Tire Size P255/70R17
Rear Tire Size P255/70R17
Spare Tire Size P255/70R17
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Wt Distributing Hitch - Max Trailer Wt. 6100 lbs
Wt Distributing Hitch - Max Tongue Wt. 610 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Maximum Trailering Capacity 10800 lbs
Base Curb Weight N/A lbs
Curb Weight - Front N/A lbs
Curb Weight - Rear N/A lbs
Option Weight - Front 0.00 lbs
Option Weight - Rear 0.00 lbs
As Spec'd Curb Weight N/A lbs
As Spec'd Payload N/A lbs
Maximum Payload Capacity N/A lbs
Gross Combined Wt Rating 12000 lbs
Gross Axle Weight Rating 7900.00 lbs
Curb Weight N/A lbs
Total Option Weight 0.00 lbs
Gross Vehicle Weight Rating 7200.00 lbs
Passenger Capacity 6
Front Head Room 42.80 in
Front Leg Room 45.27 in
Front Shoulder Room 66.03 in
Front Hip Room 60.73 in
Second Head Room 40.50 in
Second Leg Room 40.93 in
Second Shoulder Room 65.73 in
Second Hip Room 60.27 in
Wheelbase 153.0 in
Length, Overall w/o rear bumper 239.57 in
Length, Overall w/rear bumper N/A in
Length, Overall N/A in
Width, Max w/o mirrors 80.0 in
Height, Overall 73.80 in
Overhang, Front N/A in
Overhang, Rear w/o bumper N/A in
Cab to End of Frame N/A in
Ground to Top of Load Floor 34.1 in
Ground Clearance, Front 8.93 in
Ground Clearance, Rear 8.93 in
Cargo Box Length @ Floor 78.87 in
Cargo Box Width @ Top, Rear N/A in
Cargo Box Width @ Floor 64.6 in
Cargo Box Width @ Wheelhousings 51.03 in
Cargo Box (Area) Height 21.10 in
Tailgate Width 62.2 in
Cargo Volume 61.0 ft³
Ext'd Cab Cargo Volume N/A ft³
SiriusXM Satellite Radio, delete Standard
OnStar with 4G LTE and built-in Wi-Fi hotspot to connect to the internet at 4G LTE speeds, includes 3GB or 3 months OnStar Data Trial (whichever comes first) (Available 4G LTE Wi-Fi requires compatible mobile device, active OnStar subscription and data plan after trial.) Optional
6-speaker audio system (Standard on Crew Cab and Double Cab models.) Standard
Bluetooth for phone, personal cell phone connectivity to vehicle audio system Optional
Audio system, Chevrolet MyLink Radio with 7" diagonal color touch-screen, AM/FM stereo with seek-and-scan and digital clock, includes Bluetooth streaming audio for music and select phones; featuring Android Auto and Apple CarPlay capability for compatible phone (STD) Optional
Door handles, Black Standard
Headlamps, high intensity discharge (HID) projector-beam with LED signature DRL Standard
Wheels, 17" x 8" (43.2 cm x 20.3 cm) stainless steel clad (STD) Optional
Recovery hooks, front, frame-mounted, black (Included with 4WD models only.) Standard
Remote Locking Tailgate Optional
Glass, deep-tinted Optional
Mirrors, outside heated power-adjustable (includes driver's side spotter mirror) (Black.) Optional
Bumper, front chrome Optional
Tailgate and bed rail protection cap, top Standard
Tires, P255/70R17 all-season, blackwall (STD) Standard
Tire carrier lock, keyed cylinder lock that utilizes same key as ignition and door Standard
CornerStep, rear bumper Standard
Lamps, cargo area, cab mounted with switch on center switch bank Standard
Bumper, rear chrome Optional
Wheel, full-size spare, 17" (43.2 cm) steel Standard
Grille surround, chrome Standard
Tire, spare P255/70R17 all-season, blackwall (Included and only available with (RBZ) P255/70R17 all-season, blackwall tires.) Standard
Door locks, power Standard
Instrumentation, 6-gauge cluster featuring speedometer, fuel level, engine temperature, tachometer, voltage and oil pressure Standard
Steering column, Tilt-Wheel, manual with theft-deterrent locking feature Standard
Windows, power front and rear with driver express up and down and express down on all other windows Standard
Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor) (Requires Crew Cab model.) Standard
Cruise control, electronic with set and resume speed, steering wheel-mounted Standard
Floor covering, Graphite-colored rubberized-vinyl, no floor mats included Standard
Driver Information Center, 3.5-inch diagonal monochromatic display provides warning messages and basic vehicle information Standard
Remote Keyless Entry, with 2 transmitters Optional
Seats, front 40/20/40 split-bench, 3-passenger, driver and front passenger manual recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manual adjustable driver lumbar. (STD) Standard
Air conditioning, single-zone Standard
Assist handle, front passenger on A-pillar Standard
Battery, heavy-duty 720 cold-cranking amps/80 Amp-hr, maintenance-free with rundown protection and retained accessory power (Included and only available with V8 engines.) Standard
Steering, Electric Power Steering (EPS) assist, rack-and-pinion Standard
Frame, fully-boxed, hydroformed front section Standard
Pickup box Standard
Transfer case, with floor-mounted shifter (Included with 4WD models only.) Standard
Cooling, external engine oil cooler Standard
Four wheel drive Standard
GVWR, 7200 lbs. (3266 kg) (Requires Crew Cab or Double Cab 4WD models and (L83) 5.3L EcoTec3 V8 engine or (L86) 6.2L EcoTec3 V8 engine.) Standard
Cooling, auxiliary external transmission oil cooler (Included and only available with (L83) 5.3L EcoTec3 V8 engine.) Standard
Engine, 5.3L EcoTec3 V8 with Active Fuel Management, Direct Injection and Variable Valve Timing includes aluminum block construction (355 hp [265 kW] @ 5600 rpm, 383 lb-ft of torque [518 Nm] @ 4100 rpm; more than 300 lb-ft of torque from 2000 to 5600 rpm) (STD) (Standard on C*15743 models.) Standard
Alternator, 150 amps Standard
Exhaust, aluminized stainless-steel muffler and tailpipe Standard
Transmission, 6-speed automatic, electronically controlled with overdrive and tow/haul mode. Includes Cruise Grade Braking and Powertrain Grade Braking (STD) Standard
Suspension Package, Handling/Trailering Standard
Brakes, 4-wheel disc with DURALIFE rotors, 4-wheel antilock Standard
Rear axle, 3.08 ratio (Requires (L83) 5.3L EcoTec3 V8 engine. Not available with (RD2) 20" chrome wheels or (RD4) 20" polished-aluminum wheels.) Standard
OnStar Guidance plan for 6 months including Automatic Crash Response, Stolen Vehicle Assistance, Roadside Assistance, Turn-by-Turn Navigation, Advanced Diagnostics and more (trial excludes Hands-Free Calling) (Visit www.onstar.com for coverage map, details and system limitations. Services may vary by model and conditions.) Optional
StabiliTrak, stability control system with Proactive Roll Avoidance and traction control includes electronic trailer sway control and hill start assist Standard
Tire Pressure Monitoring System (does not apply to spare tire) Standard
Airbags, Dual-stage frontal airbags for driver and front passenger, seat-mounted side-impact airbags for driver and front outboard passenger, and head-curtain side-impact airbags for front and rear outboard seating positions; includes Passenger Sensing System (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.) Standard
Daytime Running Lamps with automatic exterior lamp control Standard
