2010 Ford Expedition EL King Ranch specs & colors

Sport Utility

Change trim
MSRP
2WD 4dr XLT
$39,110
4WD 4dr XLT
$42,010
2WD 4dr Eddie Bauer
$43,575
2WD 4dr Limited
$45,810
4WD 4dr Eddie Bauer
$46,470
2WD 4dr King Ranch
$48,340
4WD 4dr Limited
$48,710
4WD 4dr King Ranch
$51,240
$51,240
Starting MSRP
Current listing price
2010 Ford Expedition EL King Ranch

Showing the 2010 Ford Expedition EL 4WD 4dr King Ranch

Shop Now No inventory available.
Shop 2010 Ford Expedition EL

Key specs

Color options

Interior
Charcoal black

Packages

  • $0

    Starting MSRP

    • base vehicle

  • $6,375

    Starting MSRP

    • moonroof w/sunshade
    • navigation
    • rear seat DVD
    See more detail

    $6,375

    Starting MSRP

    • moonroof w/sunshade
    • navigation
    • rear seat DVD
    • 20" chrome clad aluminum wheels
    • P275/55R20 all-season BSW tires
    • pwr running boards

Specifications

Highlights

Gas/Ethanol V8
Engine Type
12 City / 17 Hwy
MPG
310 hp
Horsepower
7
Seating Capacity

Brakes

Not Available
Drum - Rear (Yes or )
13.0 x 1.18 in
Front Brake Rotor Diam x Thickness
Yes
Disc - Front (Yes or )
Not Available
Brake ABS System (Second Line)
Yes
Disc - Rear (Yes or )
4-Wheel
Brake ABS System
13.5 x 0.9 in
Rear Brake Rotor Diam x Thickness
Pwr
Brake Type

Electrical

150
Maximum Alternator Capacity (amps)
650
Cold Cranking Amps @ 0° F (Primary)

Engine

Gas/Ethanol V8
Engine Type
365 @ 3600
SAE Net Torque @ RPM
5.4L/330
Displacement
310 @ 5100
SAE Net Horsepower @ RPM
6-Speed A/T
A/T
Transmission Options
12 City / 17 Hwy
MPG
13 qts
Total Cooling System Capacity

Entertainment

Optional
Bluetooth®

Measurements

36 in
Ground to Top of Load Floor
78 in
Height, Overall
67 in
Third Shoulder Room
N/A
Cargo Box Width @ Floor
N/A
Cargo Box Width @ Top, Rear
9 in
Ground Clearance, Front
N/A
Length, Overall
40 in
Second Head Room
8
Passenger Capacity
N/A
Cargo Volume
51 in
Cargo Box Width @ Wheelhousings
N/A
Overhang, Rear w/o bumper
N/A
Cargo Area Length @ Floor to Console
N/A
Tailgate Width
40 in
Front Head Room
63 in
Front Shoulder Room
N/A
Ext'd Cab Cargo Volume
N/A
Side Door Opening Width
39 in
Second Leg Room
79 in
Width, Max w/o mirrors
N/A
Step Up Height - Front
41 in
Front Leg Room
86 ft³
Cargo Volume to Seat 2
N/A
Cargo Area Width @ Beltline
60 in
Second Hip Room
N/A
Side Door Opening Height
39 in
Overhang, Front
131 ft³
Cargo Volume to Seat 1
57 in
Rear Door Opening Width
64 in
Second Shoulder Room
N/A
Cargo Box (Area) Height
N/A
Cab to End of Frame
43 ft³
Cargo Volume to Seat 3
9 in
Ground Clearance, Rear
34 in
Rear Door Opening Height
29 in
Cargo Area Length @ Floor to Seat 3
60 in
Cargo Area Length @ Floor to Seat 2
38 in
Third Head Room
221 in
Length, Overall w/rear bumper
131 in
Wheelbase
98 in
Cargo Area Length @ Floor to Seat 1
N/A
Step Up Height - Side
52 in
Third Hip Room
38 in
Third Leg Room
60 in
Front Hip Room
Not Available ft³
Cargo Volume to Seat 4

Safety

Optional
Navigation System
Standard
Stability Control
Standard
Brake Assist

Steering

44 ft
Turning Diameter - Curb to Curb
Variable Pwr Rack & Pinion
Steering Type
45 ft
Turning Diameter - Wall to Wall
N/A
Steering Ratio (:1), Overall

Suspension

Independent
Axle Type - Rear
Multi-Link
Suspension Type - Rear
Independent
Axle Type - Front
Double Wishbone
Suspension Type - Front

Tires & Wheels

18 x 7.5 in
Front Wheel Size
N/A
Spare Tire Size
18 x 7.5 in
Rear Wheel Size
18 x 7.5 in
Spare Wheel Size
Aluminum
Rear Wheel Material
Aluminum
Front Wheel Material
P255/70R18
Rear Tire Size
P255/70R18
Front Tire Size
Steel
Spare Wheel Material

Weight & Capacity

7,950 lbs
Gross Axle Weight Rating
15,000 lbs
Gross Combined Wt Rating
N/A
Maximum Trailering Capacity
1,592 lbs
As Spec'd Payload
3,138 lbs
Curb Weight - Front
7,720 lbs
Gross Vehicle Weight Rating
34 gal
Fuel Tank Capacity, Approx
Not Available gal
Aux Fuel Tank Capacity, Approx
1,592 lbs
Maximum Payload Capacity
500 lbs
Dead Weight Hitch - Max Tongue Wt.
Not Available lbs
Fifth Wheel Hitch - Max Trailer Wt.
2,990 lbs
Curb Weight - Rear
0 lbs
Option Weight - Front
8,700 lbs
Wt Distributing Hitch - Max Trailer Wt.
5,000 lbs
Dead Weight Hitch - Max Trailer Wt.
Not Available lbs
Fifth Wheel Hitch - Max Tongue Wt.
N/A
Base Curb Weight
0 lbs
Option Weight - Rear
6,128 lbs
As Spec'd Curb Weight
0 lbs
Total Option Weight
6,128 lbs
Curb Weight
1,305 lbs
Wt Distributing Hitch - Max Tongue Wt.
