2012 Mazda Mazda3 i Grand Touring specs & colors

Starting MSRP
Current listing price
2012 Mazda Mazda3 i Grand Touring

Showing the 2012 Mazda Mazda3 4dr Sdn Auto i Grand Touring

Shop Now

Key specs

Color options






EPA Classification Compact
Front Wheel Size 17 x 7.0 in
Rear Wheel Size 17 x 7.0 in
Spare Wheel Size 16 x -TBD- in
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) N/A
Maximum Alternator Capacity (amps) 100
Engine Type Gas I4
Displacement 2.0L/122
SAE Net Horsepower @ RPM 155 @ 6000
SAE Net Torque @ RPM 148 @ 4100
EPA Fuel Economy Est - Hwy 40 MPG
Cruising Range - City 406.00 mi
EPA Fuel Economy Est - City 28 MPG
Fuel Economy Est-Combined 33 MPG
Cruising Range - Hwy 580.00 mi
EPA MPG Equivalent - City N/A
EPA MPG Equivalent - Hwy N/A
EPA MPG Equivalent - Combined N/A
Estimated Battery Range N/A mi
Drivetrain Front Wheel Drive
Trans Type 6
Trans Description Cont. Automatic
Trans Description Cont. Again Not Available
First Gear Ratio (:1) 3.55
Second Gear Ratio (:1) 2.02
Third Gear Ratio (:1) 1.45
Fourth Gear Ratio (:1) 1.00
Fifth Gear Ratio (:1) 0.70
Sixth Gear Ratio (:1) 0.59
Reverse Ratio (:1) N/A
Final Drive Axle Ratio (:1) 3.89
Suspension Type - Front MacPherson Strut
Suspension Type - Rear Multi-link
Suspension Type - Front (Cont.) w/Coil Springs
Suspension Type - Rear (Cont.) w/Coil Springs
Brake Type Pwr
Brake ABS System 4-wheel
Brake ABS System (Second Line) N/A
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 10.9 x -TBD- in
Rear Brake Rotor Diam x Thickness 10.4 x -TBD- in
Drum - Rear (Yes or ) Not Available
Fuel Tank Capacity, Approx 14.5 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Pwr Rack & Pinion
Steering Ratio (:1), Overall 16.2
Lock to Lock Turns (Steering) 2.94
Turning Diameter - Curb to Curb 34.2 ft
Turning Diameter - Wall to Wall 35.8 ft
Front Tire Size P205/50VR17
Rear Tire Size P205/50VR17
Spare Tire Size T125/70D16
Dead Weight Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Trailer Wt. Not Available lbs
Wt Distributing Hitch - Max Tongue Wt. Not Available lbs
Base Curb Weight 2950 lbs
Passenger Capacity 5
Passenger Volume 94.1 ft³
Front Head Room 38.9 in
Front Leg Room 42.0 in
Front Shoulder Room 54.9 in
Front Hip Room 53.7 in
Second Head Room 37.5 in
Second Leg Room 36.2 in
Second Shoulder Room 54.0 in
Second Hip Room 52.2 in
Wheelbase 103.9 in
Length, Overall 180.9 in
Width, Max w/o mirrors 69.1 in
Height, Overall 57.9 in
Track Width, Front 60.4 in
Track Width, Rear 59.8 in
Min Ground Clearance 4.7 in
Liftover Height N/A in
Trunk Volume 11.8 ft³
Center console w/covered storage compartments Standard
Sport-type matte grille insert & trim Standard
Tilt/telescopic steering column Standard
Front seat mounted driver/front passenger side-impact air bags (SRS) Standard
Cigarette lighter Standard
Reclining front bucket seats Standard
Whiplash-reducing active front headrests Standard
(3) passenger assist grips Standard
Illuminated glove box Standard
Child safety rear door locks Standard
Body-color manual-folding heated pwr mirrors Optional
Integrated rear window antenna Standard
Black roof molding Standard
Engine immobilizer anti-theft system Standard
Satellite radio prewire *Requires additional dealer-installed hardware* Standard
Front/rear side curtain air bags Standard
Collapsible steering column Standard
Gray molded cloth headliner Standard
Driver/front passenger advanced airbags (SRS) -inc: crash zone, drivers seat position, passenger weight sensors Standard
Pwr windows w/driver side 1-touch up/down feature Standard
Black urethane engine cover Standard
Rear window defogger Standard
Rear seat child safety seat lower anchors & upper tethers (LATCH) Standard
Front side window demisters Standard
Front/rear side-impact door beams Standard
Body-color front/rear bumpers Standard
Remote releases -inc: fuel door, hood, trunk Standard
Air conditioning w/pollen filter Optional
Halogen headlights Standard
Driver side storage bin Standard
Triple-H construction Standard
Trunk entrapment release system Standard
Body-color door handles Standard
Trunk lid opener cancel system (trunk latch type) Standard
Illuminated welcome mode Optional
Full cargo area trim Standard
Pwr door locks -inc: 2-stage unlocking, central locking, speed & transmission sensitive auto door lock Standard
Dynamic stability control (DSC) w/traction control system (TCS) Standard
Bluetooth hands-free phone & audio Optional
Multi-info display (MID) -inc: -inc: compact navigation system, full color display, driver info system w/outside temp display, trip computer, maintenance reminder, audio info Optional
Cargo area light Standard
Multi-reflector taillights Standard
Passenger side seatback pocket Standard
6-speed SKYACTIV-DRIVE sport automatic transmission w/OD Optional
Variable pwr rack & pinion steering Standard
Black gauges -inc: white lettering, blue accents Optional
Silver driver & passenger side decoration panels & door handles Standard
(2) coat hooks Standard
60/40 split fold-down rear seat Standard
Front/rear carpet floor mats Standard
T115/70D15 temporary spare tire Standard
Underhood insulator pad Standard
Front seat belt pretensioners w/force limiters, height adjustable Standard
Instrumentation -inc: speedometer, tachometer, (2) resettable trip odometers Standard
Stainless steel exhaust -inc: manifold, main silencer, pipe, single outlet Standard
Rear independent multi-link suspension w/coil springs Standard
Black steering wheel switch bezel Standard
265-watt Bose AM/FM stereo w/CD/MP3 player -inc: Centerpoint surround sound audio system, (10) speakers, AudioPilot noise compensation technology, aux audio input jack Optional
Front/rear stabilizer bars Standard
(2) 12-volt pwr outlets Standard
3-point seat belts for all positions Standard
Tire pressure monitoring system Standard
Parking brake w/silver button Optional
P205/50VR17 all-season tires Optional
Rear heater ducts Standard
Full carpeting Standard
Pwr front ventilated/rear solid disc brakes Standard
Anti-lock brake system w/electronic brakeforce distribution (EBD), brake assist Standard
Front independent MacPherson strut suspension w/coil springs Standard
Pwr moonroof -inc: 1-touch/global open/close, interior sunshade Optional
Dual front cupholders w/lids Standard
Front/rear outboard adjustable headrests Standard
Electro-hydraulic pwr assist steering (EHPAS) system Standard
100-amp alternator Standard
Dual vinyl-covered visors -inc: covered vanity mirrors Standard
2.0L DOHC 16-valve SKYACTIV-G I4 engine -inc: variable valve timing (VVT) Optional
Leather-wrapped black shift knob w/silver insert Optional
2-speed variable-intermittent front windshield wipers Standard
Silver center console panel Standard
Warning lamps -inc: brake system, high-beam on, turn signals on, hazard warning on, check engine, engine oil pressure, battery charge, defogger-on, air bags, front seat belt pretensioner system, door-ajar, low fuel, low coolant temp, ABS system, cruise control on, tire pressure monitoring system Standard
Lighting -inc: front map lights, dome light, ignition keyhole Standard
17" x 7.0" alloy wheels Optional
Distributor-less ignition Standard
Gauges & controls illumination w/dial-type dimming control Standard
Body-color fuel door Standard
Aluminum alloy engine block Standard
Front wheel drive Standard
Crashable brake pedal Standard
Leather seat trim Optional
Driver foot rest Standard
Synthetic leather door trim inc: front/rear bottle holders, front storage pockets Optional
Cruise control w/steering wheel mounted controls Optional
3-spoke leather wrapped steering wheel -inc: audio, cruise, Bluetooth controls Optional
