2012 Scion xB Release Series 9.0 specs & colors

Station Wagon

Change trim

MSRP

5dr Wgn Man (Natl) $16,300
5dr Wgn Auto (Natl) $17,250
5dr Wgn Man Release Series 9.0 (GS) $18,110
5dr Wgn Man Release Series 9.0 (SE) $18,110
5dr Wgn Man Release Series 9.0 (Natl) $18,110
5dr Wgn Auto Release Series 9.0 (SE) $19,060
5dr Wgn Auto Release Series 9.0 (GS) $19,060
5dr Wgn Auto Release Series 9.0 (Natl) $19,060

Change trim

$18,110

Starting MSRP
Current listing price

Showing the 2012 Scion xB 5dr Wgn Man Release Series 9.0 (Natl)

Shop Now

Color options

Exterior

Interior

No colors available

Packages

Specifications

EPA MPG Equivalent - Hwy	N/A
EPA MPG Equivalent - City	N/A
Fuel Economy Est-Combined	24 MPG
EPA Fuel Economy Est - Hwy	28 MPG
EPA MPG Equivalent - Combined	N/A
Cruising Range - Hwy	392.00 mi
Estimated Battery Range	N/A mi
EPA Fuel Economy Est - City	22 MPG
Cruising Range - City	308.00 mi

Fifth Gear Ratio (:1)	0.73
Drivetrain	Front Wheel Drive
Final Drive Axle Ratio (:1)	4.24
Reverse Ratio (:1)	3.58
First Gear Ratio (:1)	3.54
Trans Description Cont.	Manual w/OD
Third Gear Ratio (:1)	1.33
Fourth Gear Ratio (:1)	0.97
Trans Type	5
Second Gear Ratio (:1)	2.05

Front Brake Rotor Diam x Thickness	10.8 x -TBD- in
Rear Brake Rotor Diam x Thickness	11.0 x -TBD- in
Brake ABS System (Second Line)	N/A
Disc - Front (Yes or )	Yes
Brake ABS System	4-wheel
Disc - Rear (Yes or )	Yes
Brake Type	Power

Front Hip Room	52.7 in
Cargo Area Length @ Floor to Seat 1	N/A in
Second Hip Room	46.7 in
Length, Overall	167.3 in
Cargo Box Width @ Wheelhousings	N/A in
Second Leg Room	38.0 in
Track Width, Front	60.0 in
Height, Overall	63.4 in
Second Head Room	41.2 in
Front Leg Room	40.7 in
Cargo Volume to Seat 1	11.6 ft³
Second Shoulder Room	54.7 in
Cargo Area Length @ Floor to Seat 3	N/A in
Track Width, Rear	59.8 in
Min Ground Clearance	5.1 in
Cargo Volume to Seat 2	69.9 ft³
Passenger Volume	110.9 ft³
Width, Max w/o mirrors	69.3 in
Cargo Area Length @ Floor to Seat 2	N/A in
Front Shoulder Room	55.8 in
Cargo Box (Area) Height	N/A in
Liftover Height	N/A in
Trunk Volume	N/A ft³
Rear Door Opening Width	N/A in
Wheelbase	102.4 in
Passenger Capacity	5
Cargo Area Width @ Beltline	N/A in
Front Head Room	40.0 in
Rear Door Opening Height	N/A in

P205/55R16 all-season tires	Standard
Pwr door locks	Standard
Aux pwr outlet	Standard
Cruise control	Standard
Front stabilizer bar	Standard
Pwr steering	Standard
Multi-info display	Standard
Front wheel drive	Standard
Digital clock	Standard
First-aid kit	Standard
Rear wiper	Standard
Pwr outside mirrors w/turn indicators	Standard
Pwr front vented disc/rear solid disc brakes	Standard
Driver & front passenger dual-stage airbags (SRS) -inc: passenger occupant sensor	Standard
Remote keyless entry	Standard
Multi-reflector halogen headlamps w/low beam projector lamp	Standard
Air conditioning	Standard
Pwr windows w/driver side one-touch down	Standard
ISOFIX CRS top tether anchor brackets & lower anchors	Standard
Tilt steering wheel w/audio controls	Standard
3-point seat belts in all seating positions w/driver & front passenger pretensioners & force limiters	Standard
5-speed manual transmission w/OD	Standard
Tire pressure monitor system	Standard
Torsion beam rear suspension	Standard
Front seat side body airbags	Standard
2.4L DOHC SFI 16-valve VVT-i I4 engine	Standard
Deep orange instrument panel illumination	Standard
Driver & front passenger sunvisor w/vanity mirror	Standard
60/40 split fold flat rear seat w/under-seat storage tray	Standard
Release series 9.0 -inc: unique honeycomb patterned lower grille, hot lava exterior paint, dark charcoal/hot lava premium synthetic suede seat trim	Optional
Temporary spare tire	Standard
Child safety rear door locks	Standard
Chrome exhaust tip	Standard
Vehicle stability control (VSC) w/cut-off switch	Standard
Traction control	Standard
Cup holders	Standard
Front & rear side head curtain airbags	Standard
Anti-lock brake system (ABS) w/electronic brakeforce distribution (EBD)	Standard
Premium synthetic suede seat trim	Optional
160-watt Pioneer AM/FM stereo w/CD/MP3/WMA player -inc: satellite radio capability, Sound Retouch digital equalization, Scion sound processing, customizable welcome screen, (6) speakers, auxiliary audio & iPod inputs, HD radio, Bluetooth	Standard
Cargo area under-floor storage	Standard
Instrumentation-inc: tachometer, trip computer	Standard
Front sport bucket seats w/driver seat height adjustment & armrest	Standard
16" x 6.5" steel wheels w/wheel covers	Standard
Unique honeycomb patterned lower grille	Optional
Independent MacPherson strut front suspension	Standard
Intermittent windshield wipers	Standard
Center console	Standard
Rear privacy glass	Standard
Rear window defogger	Standard
Brake assist	Standard

Compare trims

Wondering which trim is right for you?

Our 2012 Scion xB trim comparison will help you decide.

Front Wheel Size	16 x 6.5 in
Spare Wheel Material	Steel
Rear Wheel Material	Steel
Rear Wheel Size	16 x 6.5 in
Front Wheel Material	Steel
Spare Wheel Size	Compact in

Displacement	2.4L/144
SAE Net Horsepower @ RPM	158 @ 6000
SAE Net Torque @ RPM	162 @ 4000
Engine Type	Gas I4

Suspension Type - Front	MacPherson Strut
Suspension Type - Rear	Torsion Beam

Fuel Tank Capacity, Approx	14.0 gal
Aux Fuel Tank Capacity, Approx	N/A gal

Lock to Lock Turns (Steering)	2.9
Turning Diameter - Curb to Curb	34.8 ft
Turning Diameter - Wall to Wall	N/A ft
Steering Ratio (:1), Overall	16.0
Steering Type	Pwr Rack & Pinion

Maximum Alternator Capacity (amps)	N/A
Cold Cranking Amps @ 0° F (Primary)	N/A

Rear Tire Size	P205/55R16
Spare Tire Size	Compact
Front Tire Size	P205/55R16

Dead Weight Hitch - Max Trailer Wt.	N/A lbs
Dead Weight Hitch - Max Tongue Wt.	N/A lbs
Wt Distributing Hitch - Max Tongue Wt.	N/A lbs
Wt Distributing Hitch - Max Trailer Wt.	N/A lbs
