2013 Ford F-150 XLT specs & colors

Regular Cab Pickup

Change trim

$29,760

Starting MSRP
Current listing price

Showing the 2013 Ford F-150 2WD Reg Cab 145" XLT

Shop Now

Key specs

2-door

3 seats

302.0-hp, 3.7-liter, V6 Cylinder Engine (Flex Fuel Capability)

19 combined MPG

213.2" length, 74.8" height

Rear Wheel Drive

Color options

Exterior

Interior

Boxster Red

Maldives Blue

Packages

BASE EQUIPMENT GROUP

$0

Starting MSRP
- std equipment
MID EQUIPMENT GROUP

$1,310

Starting MSRP
- pwr heated exterior mirrors w/integrated turn signals & driver side auto-dimming function
- auto-dimming rearview mirror
- pwr adjustable pedals
See more detail
$1,310

Starting MSRP
- pwr heated exterior mirrors w/integrated turn signals & driver side auto-dimming function
- auto-dimming rearview mirror
- pwr adjustable pedals
- SiriusXM satellite radio
- MyFord w/5-way steering wheel control switch
- 4.2" LCD audio/climate control screen in center stack
- 4.2" LCD productivity screen message center w/trip computer
- leather-wrapped steering wheel
- trailer tow pkg w/class IV trailer hitch receiver
- 7-pin wiring harness
- upgraded radiator
- aux trans oil cooler
- SelectShift auto trans

Specifications

Highlights

Gas/Ethanol V6

Engine Type

17 City / 23 Hwy

MPG

360 hp
365 hp
302 hp

Horsepower

Seating Capacity

Brakes

13.7 x 0.413 in

Rear Brake Rotor Diam x Thickness

4-Wheel

Brake ABS System

Not Available

Drum - Rear (Yes or )

Yes

Disc - Rear (Yes or )

Not Available

Brake ABS System (Second Line)

13.78 x 0.55 in

Front Brake Rotor Diam x Thickness

Pwr

Brake Type

Yes

Disc - Front (Yes or )

Electrical

155

Maximum Alternator Capacity (amps)

750

Cold Cranking Amps @ 0° F (Primary)

Engine

3.7L/227

Displacement

Gas/Ethanol V6

Engine Type

278 @ 4000

SAE Net Torque @ RPM

302 @ 6500

SAE Net Horsepower @ RPM

6-Speed A/T
Transmission Overdrive Switch
A/T
Transmission w/Dual Shift Mode

Transmission Options

17 City / 23 Hwy

MPG

15.0 qts

Total Cooling System Capacity

Entertainment

Optional

Bluetooth®

Measurements

N/A

Length, Overall w/rear bumper

N/A

Cab to End of Frame

22 in

Cargo Box (Area) Height

35 in

Ground to Top of Load Floor

N/A

Second Leg Room

61 in

Front Hip Room

41 in

Front Head Room

75 in

Height, Overall

17 ft³

Ext'd Cab Cargo Volume

41 in

Front Leg Room

232 in

Length, Overall w/o rear bumper

67 in

Front Shoulder Room

81 ft³

Cargo Volume

N/A

Second Head Room

79 in

Width, Max w/o mirrors

60 in

Cargo Box Width @ Floor

N/A

Ground Clearance, Rear

N/A

Second Shoulder Room

N/A

Length, Overall

38 in

Overhang, Front

N/A

Second Hip Room

Passenger Capacity

145 in

Wheelbase

N/A

Overhang, Rear w/o bumper

N/A

Ground Clearance, Front

60 in

Tailgate Width

50 in

Cargo Box Width @ Wheelhousings

97 in

Cargo Box Length @ Floor

60 in

Cargo Box Width @ Top, Rear

Safety

Standard

Stability Control

Steering

N/A

Steering Ratio (:1), Overall

47 ft

Turning Diameter - Curb to Curb

N/A

Turning Diameter - Wall to Wall

Pwr Rack & Pinion

Steering Type

Suspension

Live Axle

Suspension Type - Rear

Double-Wishbone

Suspension Type - Front

Long-Spindle

Axle Type - Front

Semi-Float Beam

Axle Type - Rear

Tires & Wheels

P235/75R17

Spare Tire Size

Aluminum

Rear Wheel Material

P235/75R17

Front Tire Size

Aluminum

Front Wheel Material

17 x 7.5 in

Rear Wheel Size

P235/75R17

Rear Tire Size

17 x 7.5 in

Spare Wheel Size

17 x 7.5 in

Front Wheel Size

Steel

Spare Wheel Material

Weight & Capacity

840 lbs

Wt Distributing Hitch - Max Tongue Wt.

0 lbs

Total Option Weight

0 lbs

Option Weight - Rear

1,986 lbs

Maximum Payload Capacity

7,250 lbs

Gross Axle Weight Rating

6,750 lbs

Gross Vehicle Weight Rating

Not Available gal

Aux Fuel Tank Capacity, Approx

5,600 lbs

Wt Distributing Hitch - Max Trailer Wt.

1,982 lbs

Curb Weight - Rear

N/A

Gross Combined Wt Rating

0 lbs

Option Weight - Front

4,764 lbs

Curb Weight

5,600 lbs

Fifth Wheel Hitch - Max Trailer Wt.

1,986 lbs

As Spec'd Payload

4,764 lbs

As Spec'd Curb Weight

N/A

Maximum Trailering Capacity

1,400 lbs

Fifth Wheel Hitch - Max Tongue Wt.

500 lbs

Dead Weight Hitch - Max Tongue Wt.

26 gal

Fuel Tank Capacity, Approx

N/A

Base Curb Weight

5,000 lbs

Dead Weight Hitch - Max Trailer Wt.

2,782 lbs

Curb Weight - Front
