2012 GMC Canyon SLE2 specs & colors

Crew Cab Pickup

Change trim

MSRP

Change trim

$26,470

Starting MSRP
Current listing price

Showing the 2012 GMC Canyon 2WD Crew Cab SLE2

Shop Now

Color options

Exterior

Interior

Ebony

Ebony / Light Cashmere

Packages

Specifications

Cruising Range - Hwy	437.00 mi
Estimated Battery Range	N/A mi
EPA Fuel Economy Est - Hwy	23 MPG
EPA Fuel Economy Est - City	17 MPG
Cruising Range - City	323.00 mi
Fuel Economy Est-Combined	21 MPG

Trans Type	4
Reverse Ratio (:1)	2.29
Drivetrain	Rear Wheel Drive
Trans Description Cont.	Automatic
Final Drive Axle Ratio (:1)	N/A
Fourth Gear Ratio (:1)	0.70
Third Gear Ratio (:1)	1.00
First Gear Ratio (:1)	3.06
Second Gear Ratio (:1)	1.63

Dead Weight Hitch - Max Trailer Wt.	3000 lbs
Dead Weight Hitch - Max Tongue Wt.	300 lbs
Wt Distributing Hitch - Max Tongue Wt.	450 lbs
Maximum Trailering Capacity	N/A lbs
Wt Distributing Hitch - Max Trailer Wt.	3000 lbs

Curb Weight	3728.00 lbs
Curb Weight - Front	2048 lbs
As Spec'd Curb Weight	3728.00 lbs
Total Option Weight	0.00 lbs
Gross Combined Wt Rating	7000 lbs
Gross Vehicle Weight Rating	5000.00 lbs
Gross Axle Weight Rating	5529.00 lbs
Curb Weight - Rear	1680 lbs
Base Curb Weight	N/A lbs
Maximum Payload Capacity	1272.00 lbs
As Spec'd Payload	1272.00 lbs
Option Weight - Rear	0.00 lbs
Option Weight - Front	0.00 lbs

Overhang, Rear w/o bumper	N/A in
Cargo Volume	37.0 ft³
Ground Clearance, Rear	11.4 in
Length, Overall w/rear bumper	N/A in
Ground to Top of Load Floor	35.7 in
Second Head Room	38.3 in
Ext'd Cab Cargo Volume	N/A ft³
Cargo Box Width @ Wheelhousings	42.6 in
Overhang, Front	33.9 in
Second Hip Room	52.9 in
Front Shoulder Room	57.1 in
Front Head Room	39.3 in
Cargo Box (Area) Height	18.6 in
Cargo Box Length @ Floor	61.4 in
Front Hip Room	53.3 in
Width, Max w/o mirrors	67.6 in
Length, Overall	N/A in
Wheelbase	126.0 in
Cab to End of Frame	N/A in
Length, Overall w/o rear bumper	207.1 in
Passenger Capacity	5
Tailgate Width	52.4 in
Height, Overall	65.2 in
Ground Clearance, Front	11.4 in
Cargo Box Width @ Floor	57.2 in
Second Leg Room	34.8 in
Front Leg Room	42.2 in
Second Shoulder Room	57.1 in

Suspension Package, Heavy-Duty (Not available on Extended Cab models.)	Optional
Trailering equipment includes (VR4) trailer hitch and (UY7) 7-pin sealed trailer wiring connector	Optional
Mirror, inside rearview auto-dimming with compass and outside temperature display	Standard
SiriusXM Satellite Radio is standard on nearly all 2012 GM models. Enjoy a 3-month trial to the 'XM Select' package, with over 170 channels including commercial-free music, all your favorite sports, exclusive talk and entertainment. And now add premium channels to your trial at no-cost. Welcome to the world of satellite radio. (Requires a subscription sold separately by SiriusXM after the trial period. If you decide to continue your service at the end of your subscription, service will automatically renew and bill, at the rates in effect at the time of renewal, until you call SiriusXM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm.com. Available only to those at least 18 and older in the 48 contiguous USA and D.C.)	Standard
Accents, interior Titanium Nova Silver-colored air outlets and center control stack with chrome door handle bezels, uplevel instrument cluster bezel, front upper door speaker bezel and air vent sliders	Standard
Seats, front bucket with (J) SLE Deluxe Cloth, includes integral outboard head restraint, manual recliners, center floor console with storage and armrest**	Optional
Door trim, integral armrests and driver- and front passenger-side map pockets with padded cloth inserts	Standard
Warning tones headlamp on, key-in-ignition, driver safety belt unfasten, turn signal on and critical Driver Information Center active	Standard
Tires, P215/70R16 all-season, blackwall (2WD models only with (Z85) Heavy-Duty Suspension Package. Not available or included with (LH9) 5.3L V8 SFI engine.)	Standard
Visors, driver and front passenger, padded with cloth includes front passenger vanity mirror	Standard
Wipers, front intermittent with washers	Standard
Power Convenience Package with power windows, power door locks with lockout protection, Remote Keyless Entry, (DE6) outside power-adjustable, manual-folding mirrors and (DF5) inside rearview auto-dimming mirror with compass and temperature display	Standard
Trailer hitch	Optional
Trailer wiring, 7-pin sealed connector	Optional
Wheels, 4 - 16" x 6" (40.6 cm x 15.2 cm) aluminum (2WD models only. Not available with (LH9) 5.3L V8 SFI engine.)	Standard
Tire Pressure Monitor	Standard
Brakes, 4-wheel antilock, front disc/rear drum	Standard
Assist handle, front passenger and rear outboard (Crew Cab models only.)	Standard
Transmission, 4-speed automatic, electronically controlled with overdrive (Refer to the Engine and Axle section for compatibility requirements. Must specify.)	Standard
Air dam, Ebony	Standard
Suspension, front independent with coil springs (2WD models only.)	Standard
Air bags, frontal, driver and right-front passenger with Passenger Sensing System (A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.)	Standard
Rear wheel drive	Standard
Pickup box, Fleetside, all-welded steel with double wall construction and corrosion protection with 4 cargo tie-downs, tailgate, 2-position (Locking feature not available on Regular or Extended Cab models.)	Standard
Coat hook, driver-side rear	Standard
Bedliner	Standard
Power outlets, 2 auxiliary, covered, 12-volt	Standard
StabiliTrak (Includes traction control.)	Standard
Stolen Vehicle Assistance (Deleted when (UE0) OnStar delete is ordered.)	Standard
Daytime Running Lamps with automatic exterior lamp control	Standard
Mirrors, outside power-adjustable, manual-folding, body-color	Standard
Steering column, Tilt-Wheel	Standard
Theft-deterrent system, vehicle, PASSlock	Standard
Audio system, AM/FM stereo with CD/MP3 player, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume, 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab	Standard
Moldings, color-keyed bodyside (Crew Cab models only.)	Standard
Automatic Crash Response (Deleted when (UE0) OnStar delete is ordered.)	Standard
Safety belts, 3-point, driver and right-front passenger, adjustable (center position lap belt with bench seat only)	Standard
Window, rear sliding	Optional
Steering wheel, leather-wrapped	Standard
Air bags, head curtain side-impact, front and rear outboard seating positions with Passenger Sensing System (Head Curtain Side Air Bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.)	Standard
Air conditioning, single-zone manual	Standard
Safety belts, 3-point, rear, all seating positions (Not available on Regular Cab models.)	Standard
OnStar, 6 months of Directions and Connections plan includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Remote Door Unlock, Turn-by-Turn Navigation with OnStar eNav (where available), OnStar Vehicle Diagnostics, Roadside Assistance, Remote Horn and Lights, and Hands Free Calling. (Visit onstar.com for details and system limitations.)	Standard
Tire, compact spare (Not available with (Z71) High-Stance Off-Road Suspension Package.) (Not available with Extended Cab models.)	Optional
Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, engine temperature, tachometer and Driver Information Center	Standard
Floor mats, rubberized-vinyl front and rear	Standard
Engine, 3.7L DOHC 5-cylinder SFI (242 hp [180.4 kW] @ 5600 rpm), 242 lb-ft [326.7 N-m] @ 4600 rpm) (Refer to the Engine and Axle section for compatibility requirements. Must specify.)	Optional
Tailgate, 2-position	Standard
Door locks, child security rear (Crew Cab models only)	Standard
LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats (Not available on Regular Cab models.)	Standard
Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield, driver and front passenger-side glass)	Standard
Battery, heavy-duty 590 cold-cranking amps, maintenance-free with rundown protection	Standard
Bluetooth for Phone (Deleted when (UE0) OnStar delete is ordered.)	Standard
Fog lamps, front, halogen	Standard
Fascia, front Dark Smoke Gray	Standard
Floor covering, Ebony carpeting	Standard
Alternator, 125 amps	Standard
Suspension, rear semi-floating axle with 2-stage multi-leaf springs	Standard
Differential, automatic locking rear	Optional
Seats, second row, flat-folding (Crew Cab models only)	Standard
Cruise control	Standard
GVWR, 5000 lbs. (2268 kg) (2WD Extended and Crew Cab models only. Refer to the Engine and Axle section for compatibility requirements. Must specify.)	Standard
Audio system feature, uplevel speaker system	Standard
Rear axle, 3.73 ratio (Refer to the Engine and Axle section for compatibility requirements. Must specify.)	Standard
Bumpers, front and rear chrome with a Dark Smoke Gray pad on the rear step-style bumper	Standard
OnStar Turn-by-Turn Navigation (Deleted when (UE0) OnStar delete is ordered.)	Standard
Steering, power, rack-and-pinion	Standard

Compare trims

Wondering which trim is right for you?

Our 2012 GMC Canyon trim comparison will help you decide.

Spare Wheel Size	Compact in
Spare Wheel Material	Steel
Rear Wheel Size	16 x 6 in
Front Wheel Size	16 x 6 in
Front Wheel Material	Aluminum
Rear Wheel Material	Aluminum

Displacement	3.7L/226
Engine Type	Gas I5
SAE Net Torque @ RPM	242 @ 4600
SAE Net Horsepower @ RPM	242 @ 5600

Axle Type - Rear	Semi-Floating
Suspension Type - Front	Coil Springs
Suspension Type - Rear	2-Stage Multi-Leaf
Axle Type - Front	Independent

Drum - Rear (Yes or )	Yes
Disc - Front (Yes or )	Yes
Brake Type	Pwr
Front Brake Rotor Diam x Thickness	11.2 x 1.6 in
Brake ABS System	4-Wheel

Turning Diameter - Curb to Curb	44.3 ft
Turning Diameter - Wall to Wall	N/A ft
Steering Ratio (:1), Overall	N/A
Steering Type	Pwr

Cold Cranking Amps @ 0° F (Primary)	590
Maximum Alternator Capacity (amps)	125

Spare Tire Size	Compact
Front Tire Size	P215/70R16
Rear Tire Size	P215/70R16
