Interior
Ebony
Ebony / Light Cashmere
| Rear Wheel Material | Aluminum |
| Rear Wheel Size | 17 x 7 in |
| Front Wheel Material | Aluminum |
| Spare Wheel Material | Steel |
| Front Wheel Size | 17 x 7 in |
| Spare Wheel Size | Compact in |
| Cold Cranking Amps @ 0° F (Primary) | 590 |
| Maximum Alternator Capacity (amps) | 125 |
| Displacement | 3.7L/226 |
| Engine Type | Gas I5 |
| SAE Net Torque @ RPM | 242 @ 4600 |
| SAE Net Horsepower @ RPM | 242 @ 5600 |
| Estimated Battery Range | N/A mi |
| Cruising Range - Hwy | 437.00 mi |
| Fuel Economy Est-Combined | 19 MPG |
| Cruising Range - City | 323.00 mi |
| EPA Fuel Economy Est - Hwy | 23 MPG |
| EPA Fuel Economy Est - City | 17 MPG |
| Fourth Gear Ratio (:1) | 0.70 |
| Trans Type | 4 |
| Second Gear Ratio (:1) | 1.63 |
| Transfer Case Model | T150 |
| Drivetrain | 4-Wheel Drive |
| Reverse Ratio (:1) | 2.29 |
| Transfer Case Gear Ratio (:1), High | 1.00 |
| Final Drive Axle Ratio (:1) | N/A |
| Transfer Case Gear Ratio (:1), Low | 2.48 |
| Trans Description Cont. | Automatic |
| First Gear Ratio (:1) | 3.06 |
| Third Gear Ratio (:1) | 1.00 |
| Suspension Type - Front | Torsion Bar |
| Suspension Type - Rear | 2-Stage Multi-Leaf |
| Axle Type - Rear | Semi-Floating |
| Axle Type - Front | Independent |
| Frame Type | Ladder |
| Brake Type | Pwr |
| Front Brake Rotor Diam x Thickness | 11.2 x 1.6 in |
| Brake ABS System | 4-Wheel |
| Disc - Front (Yes or ) | Yes |
| Drum - Rear (Yes or ) | Yes |
| Fuel Tank Capacity, Approx | 19 gal |
| Steering Type | Pwr |
| Turning Diameter - Curb to Curb | 44.3 ft |
| Steering Ratio (:1), Overall | N/A |
| Turning Diameter - Wall to Wall | N/A ft |
| Front Tire Size | P265/70R17 |
| Rear Tire Size | P265/70R17 |
| Spare Tire Size | Compact |
| Dead Weight Hitch - Max Tongue Wt. | 290 lbs |
| Dead Weight Hitch - Max Trailer Wt. | 2900 lbs |
| Wt Distributing Hitch - Max Tongue Wt. | 435 lbs |
| Wt Distributing Hitch - Max Trailer Wt. | 2900 lbs |
| Maximum Trailering Capacity | N/A lbs |
| Total Option Weight | 0.00 lbs |
| Curb Weight - Rear | 1640 lbs |
| Base Curb Weight | N/A lbs |
| As Spec'd Curb Weight | 3878.00 lbs |
| Gross Vehicle Weight Rating | 5300.00 lbs |
| Curb Weight - Front | 2238 lbs |
| Maximum Payload Capacity | 1422.00 lbs |
| Option Weight - Rear | 0.00 lbs |
| As Spec'd Payload | 1422.00 lbs |
| Gross Combined Wt Rating | 7000 lbs |
| Curb Weight | 3878.00 lbs |
| Gross Axle Weight Rating | 5746.00 lbs |
| Option Weight - Front | 0.00 lbs |
| Ground Clearance, Front | 11.4 in |
| Front Head Room | 39.6 in |
| Length, Overall w/o rear bumper | 207.1 in |
| Second Hip Room | 57.6 in |
| Cargo Volume | 44.0 ft³ |
| Overhang, Rear w/o bumper | N/A in |
| Ground to Top of Load Floor | 31.9 in |
| Ground Clearance, Rear | 11.4 in |
| Overhang, Front | 33.9 in |
| Length, Overall w/rear bumper | N/A in |
| Cargo Box Length @ Floor | 72.8 in |
| Passenger Capacity | 4 |
| Second Head Room | 37.9 in |
| Wheelbase | 126.0 in |
| Height, Overall | 67.9 in |
| Front Leg Room | 42.2 in |
| Cab to End of Frame | N/A in |
| Cargo Box Width @ Floor | 57.2 in |
| Tailgate Width | 52.4 in |
| Second Shoulder Room | 57.2 in |
| Front Hip Room | 53.3 in |
| Ext'd Cab Cargo Volume | N/A ft³ |
| Front Shoulder Room | 57.1 in |
| Length, Overall | N/A in |
| Cargo Box (Area) Height | 18.6 in |
| Width, Max w/o mirrors | 68.6 in |
| Cargo Box Width @ Wheelhousings | 42.6 in |
| Second Leg Room | 23.1 in |
| Window, rear sliding | Optional |
| Recovery hooks, 2 front, frame-mounted (Standard on 4WD models. Included and only available with (Z71) High-Stance Off-Road Suspension Package on 2WD models.) | Optional |
| Coat hook, driver-side rear | Standard |
| Transfer case, Insta-Trac electronic shift with dash-mounted controls (4WD models only.) | Standard |
| Power outlets, 2 auxiliary, covered, 12-volt | Standard |
| Cruise control | Standard |
| Wipers, front intermittent with washers | Standard |
| Brakes, 4-wheel antilock, front disc/rear drum | Standard |
| StabiliTrak (Includes traction control.) | Standard |
| Assist handle, front passenger (Regular and Extended Cab models only.) | Optional |
| Wheels, 4 - 17" x 7" (43.2 cm x 17.8 cm) chrome clad (Included and only available with (Z71) High Stance Off-Road Suspension Package. Upgradeable to (P31) 18" x 7.5" chrome aluminum wheels.) | Optional |
| GVWR, 5300 lbs. (2404 kg) (Not available on Regular Cab models. Included and only available with (Z71) High Stance Off-Road Suspension Package on 2WD models. Standard on 4WD Extended and Crew Cab models. Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Optional |
| Stolen Vehicle Assistance (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Pickup box, Fleetside, all-welded steel with double wall construction and corrosion protection with 4 cargo tie-downs, tailgate, 2-position (Locking feature not available on Regular or Extended Cab models.) | Standard |
| Differential, automatic locking rear | Optional |
| Visors, driver and front passenger, padded with cloth includes front passenger vanity mirror | Standard |
| SiriusXM Satellite Radio is standard on nearly all 2012 GM models. Enjoy a 3-month trial to the 'XM Select' package, with over 170 channels including commercial-free music, all your favorite sports, exclusive talk and entertainment. And now add premium channels to your trial at no-cost. Welcome to the world of satellite radio. (Requires a subscription sold separately by SiriusXM after the trial period. If you decide to continue your service at the end of your subscription, service will automatically renew and bill, at the rates in effect at the time of renewal, until you call SiriusXM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm.com. Available only to those at least 18 and older in the 48 contiguous USA and D.C.) | Optional |
| Rear axle, 3.73 ratio (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Daytime Running Lamps with automatic exterior lamp control | Standard |
| Theft-deterrent system, vehicle, PASSlock | Standard |
| Air bags, frontal, driver and right-front passenger with Passenger Sensing System (A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.) | Standard |
| Audio system, AM/FM stereo with CD/MP3 player, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume, 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab | Optional |
| Floor covering, Ebony carpeting | Standard |
| Steering, power, rack-and-pinion | Standard |
| Safety belts, 3-point, driver and right-front passenger, adjustable (center position lap belt with bench seat only) | Standard |
| Steering column, Tilt-Wheel | Standard |
| LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats (Not available on Regular Cab models.) | Optional |
| Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield, driver and front passenger-side glass) | Optional |
| Mirrors, outside power-adjustable, manual-folding, body-color | Optional |
| Battery, heavy-duty 590 cold-cranking amps, maintenance-free with rundown protection | Standard |
| Fog lamps, front, halogen | Optional |
| Suspension, front independent with torsion bar (Standard on 4WD models. Included with (Z71) High-Stance Off-Road Suspension Package. Included on 2WD Extended and Crew Cab models with (Z85) Heavy-Duty Suspension Package.) | Optional |
| Safety belts, 3-point, rear, all seating positions (Not available on Regular Cab models.) | Optional |
| Floor mats, rubberized-vinyl front and rear | Standard |
| Suspension Package, High Stance Off-Road includes (R03) 4 - 17" x 7" (43.2 cm x 17.8 cm) chrome clad wheels, (QJP) P265/70R17 on-/off-road, blackwall tires, front torsion bars, 28mm front stabilizer bar, urethane jounce bumpers, (B71) large wheel flares and (G80) automatic locking rear differential (Standard on Extended Cab models. Wheels and tires are upgradeable to (P31) 18" x 7.5" chrome aluminum wheels and (QXN) P265/65R18 on/off-road, blackwall tires.) | Optional |
| Trailer wiring, 7-pin sealed connector | Optional |
| Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, engine temperature, tachometer and Driver Information Center | Standard |
| Trailer hitch | Optional |
| Steering wheel, leather-wrapped | Standard |
| Automatic Crash Response (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Fascia, front Dark Smoke Gray | Standard |
| Power Convenience Package with power windows, power door locks with lockout protection, Remote Keyless Entry, (DE6) outside power-adjustable, manual-folding mirrors and (DF5) inside rearview auto-dimming mirror with compass and temperature display | Optional |
| Accents, interior Titanium Nova Silver-colored air outlets and center control stack with chrome door handle bezels, uplevel instrument cluster bezel, front upper door speaker bezel and air vent sliders | Standard |
| Bluetooth for Phone (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Trailering equipment includes (VR4) trailer hitch and (UY7) 7-pin sealed trailer wiring connector | Optional |
| Four wheel drive | Standard |
| Tires, P265/70R17 on-/off-road, blackwall (Requires (ZNF) P235/75R16 on-/off-road blackwall spare tire. Included and only available with (Z71) High Stance Off-road Suspension Package.) | Optional |
| Tire, spare P235/75R16 all-season, blackwall (Not available on 2WD Regular Cab models. Requires (QNF) P235/75R16 all-season blackwall tires with (Z85) Heavy-Duty Suspension Package. Included with (Z71) High-Stance Off-Road Suspension Package.) | Optional |
| OnStar Turn-by-Turn Navigation (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Bumpers, front and rear chrome with a Dark Smoke Gray pad on the rear step-style bumper | Standard |
| Seats, driver- and passenger-side, forward-facing, flat-folding rear includes rear seat storage compartment (Extended Cab models only.) | Optional |
| Mirror, inside rearview auto-dimming with compass and outside temperature display | Optional |
| Tailgate, 2-position | Standard |
| Engine, 3.7L DOHC 5-cylinder SFI (242 hp [180.4 kW] @ 5600 rpm), 242 lb-ft [326.7 N-m] @ 4600 rpm) (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Optional |
| Transmission, 4-speed automatic, electronically controlled with overdrive (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Air bags, head curtain side-impact, front and rear outboard seating positions with Passenger Sensing System (Head Curtain Side Air Bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.) | Standard |
| Door trim, integral armrests and driver- and front passenger-side map pockets with padded cloth inserts | Standard |
| Air conditioning, single-zone manual | Standard |
| Audio system feature, uplevel speaker system | Standard |
| Warning tones headlamp on, key-in-ignition, driver safety belt unfasten, turn signal on and critical Driver Information Center active | Standard |
| OnStar, 6 months of Directions and Connections plan includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Remote Door Unlock, Turn-by-Turn Navigation with OnStar eNav (where available), OnStar Vehicle Diagnostics, Roadside Assistance, Remote Horn and Lights, and Hands Free Calling. (Visit onstar.com for details and system limitations.) | Standard |
| Alternator, 125 amps | Standard |
| Wheel flares, front and rear, large, body-color (Z71 only) (Included and only available with (Z71) High Stance Off-road Suspension Package.) | Optional |
| Bedliner | Standard |
| Tire Pressure Monitor | Standard |
| Suspension, rear semi-floating axle with 2-stage multi-leaf springs | Standard |
| Air dam, Ebony | Standard |
| Seats, front bucket with (**J) SLE Deluxe Cloth, includes integral outboard head restraint, manual recliners, center floor console with storage and armrest | Optional |
