Interior
Cashmere / Ebony
Ebony
| Rear Wheel Material | Aluminum |
| Front Wheel Material | Aluminum |
| Spare Wheel Size | Compact in |
| Rear Wheel Size | 16 x 6 in |
| Front Wheel Size | 16 x 6 in |
| Spare Wheel Material | Steel |
| Maximum Alternator Capacity (amps) | 125 |
| Cold Cranking Amps @ 0° F (Primary) | 590 |
| SAE Net Torque @ RPM | 242 @ 4600 |
| Engine Type | Gas I5 |
| Displacement | 3.7L/226 |
| SAE Net Horsepower @ RPM | 242 @ 5600 |
| EPA Fuel Economy Est - City | 16 MPG |
| EPA Fuel Economy Est - Hwy | 21 MPG |
| Estimated Battery Range | N/A mi |
| Cruising Range - City | 304.00 mi |
| Cruising Range - Hwy | 399.00 mi |
| Fuel Economy Est-Combined | 18 MPG |
| Fourth Gear Ratio (:1) | 0.70 |
| Trans Description Cont. | Automatic |
| Transfer Case Gear Ratio (:1), High | 1.00 |
| Trans Type | 4 |
| Transfer Case Model | T150 |
| Second Gear Ratio (:1) | 1.63 |
| Reverse Ratio (:1) | 2.29 |
| Final Drive Axle Ratio (:1) | N/A |
| First Gear Ratio (:1) | 3.06 |
| Transfer Case Gear Ratio (:1), Low | 2.48 |
| Third Gear Ratio (:1) | 1.00 |
| Drivetrain | 4-Wheel Drive |
| Suspension Type - Rear | 2-Stage Multi-Leaf |
| Suspension Type - Front | Torsion Bar |
| Axle Type - Front | Independent |
| Axle Type - Rear | Semi-Floating |
| Frame Type | Ladder |
| Brake Type | Pwr |
| Brake ABS System | 4-Wheel |
| Front Brake Rotor Diam x Thickness | 11.2 x 1.6 in |
| Drum - Rear (Yes or ) | Yes |
| Disc - Front (Yes or ) | Yes |
| Fuel Tank Capacity, Approx | 19 gal |
| Turning Diameter - Curb to Curb | 44.3 ft |
| Turning Diameter - Wall to Wall | N/A ft |
| Steering Ratio (:1), Overall | N/A |
| Steering Type | Pwr |
| Spare Tire Size | Compact |
| Rear Tire Size | P235/75R16 |
| Front Tire Size | P235/75R16 |
| Wt Distributing Hitch - Max Trailer Wt. | 5500 lbs |
| Wt Distributing Hitch - Max Tongue Wt. | 825 lbs |
| Dead Weight Hitch - Max Trailer Wt. | 5000 lbs |
| Maximum Trailering Capacity | N/A lbs |
| Dead Weight Hitch - Max Tongue Wt. | 500 lbs |
| Gross Combined Wt Rating | 9800 lbs |
| Curb Weight | 4070.00 lbs |
| Option Weight - Rear | 0.00 lbs |
| Gross Vehicle Weight Rating | 5300.00 lbs |
| As Spec'd Curb Weight | 4070.00 lbs |
| Base Curb Weight | N/A lbs |
| Curb Weight - Front | 2311 lbs |
| As Spec'd Payload | 1230.00 lbs |
| Gross Axle Weight Rating | 5746.00 lbs |
| Total Option Weight | 0.00 lbs |
| Maximum Payload Capacity | 1230.00 lbs |
| Curb Weight - Rear | 1759 lbs |
| Option Weight - Front | 0.00 lbs |
| Tailgate Width | 52.4 in |
| Ground to Top of Load Floor | 30.1 in |
| Height, Overall | 67.9 in |
| Passenger Capacity | 5 |
| Cargo Box Width @ Floor | 57.2 in |
| Second Shoulder Room | 57.1 in |
| Overhang, Front | 33.9 in |
| Ground Clearance, Rear | 11.4 in |
| Ground Clearance, Front | 11.4 in |
| Second Head Room | 38.3 in |
| Front Leg Room | 42.2 in |
| Length, Overall w/rear bumper | N/A in |
| Wheelbase | 126.0 in |
| Front Shoulder Room | 57.1 in |
| Ext'd Cab Cargo Volume | N/A ft³ |
| Width, Max w/o mirrors | 68.6 in |
| Cargo Box Width @ Wheelhousings | 42.6 in |
| Overhang, Rear w/o bumper | N/A in |
| Cab to End of Frame | N/A in |
| Cargo Box Length @ Floor | 61.4 in |
| Front Hip Room | 53.3 in |
| Length, Overall | N/A in |
| Cargo Box (Area) Height | 18.6 in |
| Length, Overall w/o rear bumper | 207.1 in |
| Front Head Room | 39.3 in |
| Second Hip Room | 52.9 in |
| Second Leg Room | 34.8 in |
| Cargo Volume | 37.0 ft³ |
| Transmission, 4-speed automatic, electronically controlled with overdrive (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Accents, interior Titanium Nova Silver-colored air outlets and center control stack with chrome door handle bezels, uplevel instrument cluster bezel, front upper door speaker bezel and air vent sliders | Standard |
| Engine, 3.7L DOHC 5-cylinder SFI (242 hp [180.4 kW] @ 5600 rpm), 242 lb-ft [326.7 N-m] @ 4600 rpm) (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Optional |
| Theft-deterrent system, vehicle, PASSlock | Standard |
| SiriusXM Satellite Radio is standard on nearly all 2012 GM models. Enjoy a 3-month trial to the 'XM Select' package, with over 170 channels including commercial-free music, all your favorite sports, exclusive talk and entertainment. And now add premium channels to your trial at no-cost. Welcome to the world of satellite radio. (Requires a subscription sold separately by SiriusXM after the trial period. If you decide to continue your service at the end of your subscription, service will automatically renew and bill, at the rates in effect at the time of renewal, until you call SiriusXM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm.com. Available only to those at least 18 and older in the 48 contiguous USA and D.C.) | Standard |
| Transfer case, Insta-Trac electronic shift with dash-mounted controls (4WD models only.) | Standard |
| Tire Pressure Monitor | Standard |
| Moldings, color-keyed bodyside (Crew Cab models only.) | Standard |
| Steering wheel, leather-wrapped | Standard |
| Suspension, front independent with torsion bar | Optional |
| Floor mats, rubberized-vinyl front and rear | Standard |
| Tailgate, 2-position | Standard |
| Trailering equipment includes (VR4) trailer hitch and (UY7) 7-pin sealed trailer wiring connector | Optional |
| Floor covering, Ebony carpeting | Standard |
| Front underbody shield | Optional |
| Bumpers, front and rear chrome with a Dark Smoke Gray pad on the rear step-style bumper | Standard |
| Pickup box, Fleetside, all-welded steel with double wall construction and corrosion protection with 4 cargo tie-downs, tailgate, 2-position (Locking feature not available on Regular or Extended Cab models.) | Standard |
| GVWR, 5300 lbs. (2404 kg) (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Optional |
| Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield, driver and front passenger-side glass) | Standard |
| Door locks, child security rear (Crew Cab models only) | Standard |
| Window, rear sliding | Optional |
| Differential, automatic locking rear | Optional |
| Assist handle, front passenger and rear outboard (Crew Cab models only.) | Standard |
| Safety belts, 3-point, rear, all seating positions | Optional |
| LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats | Optional |
| Automatic Crash Response (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Air conditioning, single-zone manual | Standard |
| Four wheel drive | Standard |
| Wipers, front intermittent with washers | Standard |
| Stolen Vehicle Assistance (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Brakes, 4-wheel antilock, front disc/rear drum | Standard |
| Wheel flares, front and rear, large, body-color (Z71 only) (Included and only available with (Z71) High Stance Off-road Suspension Package.) | Optional |
| Mirror, inside rearview auto-dimming with compass and outside temperature display | Standard |
| Suspension, rear semi-floating axle with 2-stage multi-leaf springs | Standard |
| StabiliTrak (Includes traction control.) | Standard |
| Bedliner | Standard |
| Recovery hooks, 2 front, frame-mounted | Optional |
| Rear axle, 3.73 ratio (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Bluetooth for Phone (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Safety belts, 3-point, driver and right-front passenger, adjustable (center position lap belt with bench seat only) | Standard |
| Suspension Package, High Stance Off-Road includes (R03) 4 - 17" x 7" (43.2 cm x 17.8 cm) chrome clad wheels, (QJP) P265/70R17 on-/off-road, blackwall tires, front torsion bars, 28mm front stabilizer bar, urethane jounce bumpers, (B71) large wheel flares and (G80) automatic locking rear differential | Optional |
| Air bags, head curtain side-impact, front and rear outboard seating positions with Passenger Sensing System (Head Curtain Side Air Bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.) | Standard |
| Door trim, integral armrests and driver- and front passenger-side map pockets with padded cloth inserts | Standard |
| Coat hook, driver-side rear | Standard |
| Visors, driver and front passenger, padded with cloth includes front passenger vanity mirror | Standard |
| OnStar Turn-by-Turn Navigation (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Tires, P265/70R17 on-/off-road, blackwall (Requires (ZNF) P235/75R16 on-/off-road blackwall spare tire. Included and only available with (Z71) High Stance Off-road Suspension Package.) | Optional |
| Audio system, AM/FM stereo with CD/MP3 player, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume, 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab | Standard |
| Mirrors, outside power-adjustable, manual-folding, body-color | Standard |
| Power outlets, 2 auxiliary, covered, 12-volt | Standard |
| Steering column, Tilt-Wheel | Standard |
| Tire, spare P235/75R16 all-season, blackwall (Not available on 2WD Regular Cab models. Requires (QNF) P235/75R16 all-season blackwall tires with (Z85) Heavy-Duty Suspension Package. Included with (Z71) High-Stance Off-Road Suspension Package.) | Optional |
| Daytime Running Lamps with automatic exterior lamp control | Standard |
| Warning tones headlamp on, key-in-ignition, driver safety belt unfasten, turn signal on and critical Driver Information Center active | Standard |
| Air bags, frontal, driver and right-front passenger with Passenger Sensing System (A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.) | Standard |
| Wheels, 4 - 17" x 7" (43.2 cm x 17.8 cm) chrome clad (Included and only available with (Z71) High Stance Off-Road Suspension Package. Upgradeable to (P31) 18" x 7.5" chrome aluminum wheels.) | Optional |
| Audio system feature, uplevel speaker system | Standard |
| Fascia, front Dark Smoke Gray | Standard |
| Cruise control | Standard |
| Power Convenience Package with power windows, power door locks with lockout protection, Remote Keyless Entry, (DE6) outside power-adjustable, manual-folding mirrors and (DF5) inside rearview auto-dimming mirror with compass and temperature display | Standard |
| Trailer hitch | Standard |
| Fog lamps, front, halogen | Standard |
| Steering, power, rack-and-pinion | Standard |
| Alternator, 125 amps | Standard |
| Trailer wiring, 7-pin sealed connector | Standard |
| Seats, front bucket with leather-appointed seating, 8-way power driver seat adjuster, 6-way power front passenger seat adjuster, heated driver and front passenger seats with power lumbar control and adjustable outboard head restraints | Optional |
| Seats, second row, flat-folding (Crew Cab models only) | Standard |
| Air dam, Ebony | Standard |
| Battery, heavy-duty 590 cold-cranking amps, maintenance-free with rundown protection | Standard |
| Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, engine temperature, tachometer and Driver Information Center | Standard |
| OnStar, 6 months of Directions and Connections plan includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Remote Door Unlock, Turn-by-Turn Navigation with OnStar eNav (where available), OnStar Vehicle Diagnostics, Roadside Assistance, Remote Horn and Lights, and Hands Free Calling. (Visit onstar.com for details and system limitations.) | Standard |
