Interior
Ebony
Ebony / Light Cashmere
| Spare Wheel Material | Steel |
| Front Wheel Material | Aluminum |
| Rear Wheel Size | 16 x 6 in |
| Front Wheel Size | 16 x 6 in |
| Rear Wheel Material | Aluminum |
| Spare Wheel Size | Compact in |
| Maximum Alternator Capacity (amps) | 125 |
| Cold Cranking Amps @ 0° F (Primary) | 590 |
| Engine Type | Gas I5 |
| SAE Net Torque @ RPM | 242 @ 4600 |
| Displacement | 3.7L/226 |
| SAE Net Horsepower @ RPM | 242 @ 5600 |
| Estimated Battery Range | N/A mi |
| Cruising Range - Hwy | 399.00 mi |
| EPA Fuel Economy Est - City | 16 MPG |
| Fuel Economy Est-Combined | 18 MPG |
| Cruising Range - City | 304.00 mi |
| EPA Fuel Economy Est - Hwy | 21 MPG |
| Final Drive Axle Ratio (:1) | N/A |
| Transfer Case Gear Ratio (:1), Low | 2.48 |
| Transfer Case Gear Ratio (:1), High | 1.00 |
| Trans Description Cont. | Automatic |
| Drivetrain | 4-Wheel Drive |
| Fourth Gear Ratio (:1) | 0.70 |
| Transfer Case Model | T150 |
| Trans Type | 4 |
| Third Gear Ratio (:1) | 1.00 |
| First Gear Ratio (:1) | 3.06 |
| Reverse Ratio (:1) | 2.29 |
| Second Gear Ratio (:1) | 1.63 |
| Suspension Type - Front | Torsion Bar |
| Axle Type - Front | Independent |
| Axle Type - Rear | Semi-Floating |
| Suspension Type - Rear | 2-Stage Multi-Leaf |
| Frame Type | Ladder |
| Drum - Rear (Yes or ) | Yes |
| Brake ABS System | 4-Wheel |
| Brake Type | Pwr |
| Disc - Front (Yes or ) | Yes |
| Front Brake Rotor Diam x Thickness | 11.2 x 1.6 in |
| Fuel Tank Capacity, Approx | 19 gal |
| Steering Type | Pwr |
| Turning Diameter - Wall to Wall | N/A ft |
| Steering Ratio (:1), Overall | N/A |
| Turning Diameter - Curb to Curb | 44.3 ft |
| Spare Tire Size | Compact |
| Rear Tire Size | P235/75R16 |
| Front Tire Size | P235/75R16 |
| Wt Distributing Hitch - Max Trailer Wt. | 5500 lbs |
| Maximum Trailering Capacity | N/A lbs |
| Wt Distributing Hitch - Max Tongue Wt. | 825 lbs |
| Dead Weight Hitch - Max Tongue Wt. | 500 lbs |
| Dead Weight Hitch - Max Trailer Wt. | 5000 lbs |
| Curb Weight - Front | 2311 lbs |
| As Spec'd Payload | 1230.00 lbs |
| As Spec'd Curb Weight | 4070.00 lbs |
| Curb Weight | 4070.00 lbs |
| Option Weight - Front | 0.00 lbs |
| Curb Weight - Rear | 1759 lbs |
| Gross Vehicle Weight Rating | 5300.00 lbs |
| Gross Axle Weight Rating | 5746.00 lbs |
| Gross Combined Wt Rating | 9800 lbs |
| Base Curb Weight | N/A lbs |
| Maximum Payload Capacity | 1230.00 lbs |
| Option Weight - Rear | 0.00 lbs |
| Total Option Weight | 0.00 lbs |
| Overhang, Front | 33.9 in |
| Length, Overall w/rear bumper | N/A in |
| Tailgate Width | 52.4 in |
| Front Shoulder Room | 57.1 in |
| Second Leg Room | 34.8 in |
| Ground Clearance, Front | 10.4 in |
| Cargo Box Width @ Wheelhousings | 42.6 in |
| Second Hip Room | 52.9 in |
| Ground Clearance, Rear | 10.4 in |
| Width, Max w/o mirrors | 68.6 in |
| Cargo Box Width @ Floor | 57.2 in |
| Ext'd Cab Cargo Volume | N/A ft³ |
| Height, Overall | 67.9 in |
| Cargo Volume | 37.0 ft³ |
| Cargo Box Length @ Floor | 61.4 in |
| Second Head Room | 38.3 in |
| Second Shoulder Room | 57.1 in |
| Length, Overall | N/A in |
| Ground to Top of Load Floor | 30.1 in |
| Front Head Room | 39.3 in |
| Cargo Box (Area) Height | 18.6 in |
| Front Hip Room | 53.3 in |
| Length, Overall w/o rear bumper | 207.1 in |
| Overhang, Rear w/o bumper | N/A in |
| Cab to End of Frame | N/A in |
| Wheelbase | 126.0 in |
| Passenger Capacity | 6 |
| Front Leg Room | 42.2 in |
| Fascia, front Dark Smoke Gray | Standard |
| Tire Pressure Monitor | Standard |
| OnStar Turn-by-Turn Navigation (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Steering, power, rack-and-pinion | Standard |
| Seats, second row, flat-folding (Crew Cab models only) | Standard |
| Moldings, color-keyed bodyside (Crew Cab models only.) | Standard |
| Steering column, Tilt-Wheel | Standard |
| OnStar, 6 months of Directions and Connections plan includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Remote Door Unlock, Turn-by-Turn Navigation with OnStar eNav (where available), OnStar Vehicle Diagnostics, Roadside Assistance, Remote Horn and Lights, and Hands Free Calling. (Visit onstar.com for details and system limitations.) | Standard |
| Safety belts, 3-point, driver and right-front passenger, adjustable (center position lap belt with bench seat only) | Standard |
| Wipers, front intermittent with washers | Standard |
| Air bags, head curtain side-impact, front and rear outboard seating positions with Passenger Sensing System (Head Curtain Side Air Bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.) | Standard |
| Recovery hooks, 2 front, frame-mounted (Not available on 2WD Regular Cab models. Standard on 4WD models. Included and only available with (Z71) High-Stance Off-Road Suspension Package on 2WD Extended and Crew Cab models.) | Standard |
| Rear axle, 3.73 ratio (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Wheels, 4 - 16" x 6" (40.6 cm x 15.2 cm) aluminum (Included and only available on 2WD models with (LH9) 5.3L V8 SFI engine. Packaged on 4WD Regular and Extended Cab models. Standard on 4WD Crew Cab models. Not available on 2WD Regular or Extended Cab models.) | Standard |
| Transmission, 4-speed automatic, electronically controlled with overdrive (Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Suspension, rear semi-floating axle with 2-stage multi-leaf springs | Standard |
| Differential, automatic locking rear (Standard on 4WD. Standard on Crew Cab models. Available on 2WD Extended Cab models.) | Standard |
| Warning tones headlamp on, key-in-ignition, driver safety belt unfasten, turn signal on and critical Driver Information Center active | Standard |
| Tires, P235/75R16 all-season, blackwall (Not available on 2WD Regular Cab models. Standard on 4WD models with (Z85) Heavy-Duty Suspension Package and (ZCY) compact spare tire or (ZNF) P235/75R16 on-/off-road blackwall spare tire. Included and only available on 2WD models with (LH9) 5.3L V8 SFI engine, (Z85) Heavy-Duty Suspension Package and (ZNF) P235/75R16 on-/off-road blackwall spare tire.) | Standard |
| Steering wheel, leather-wrapped | Standard |
| Brakes, 4-wheel antilock, front disc/rear drum | Standard |
| Audio system, AM/FM stereo with CD/MP3 player, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume, 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab | Standard |
| Trailer wiring, 7-pin sealed connector | Standard |
| Front underbody shield (Standard on 4WD models. Included and only available with (LH9) 5.3L V8 SFI engine and (Z71) High Stance Off-Road Suspension Package on 2WD Crew Cab models.) | Standard |
| Seats, front 60/40 split-bench with (**J) Deluxe Cloth, manual recliners, integral outboard head restraints, armrest with integral storage and dual cup holders | Standard |
| Door trim, integral armrests and driver- and front passenger-side map pockets with padded cloth inserts | Standard |
| Cruise control | Standard |
| Power outlets, 2 auxiliary, covered, 12-volt | Standard |
| Audio system feature, uplevel speaker system | Standard |
| Tire, compact spare (Not available with (Z71) High-Stance Off-Road Suspension Package.) | Standard |
| Pickup box, Fleetside, all-welded steel with double wall construction and corrosion protection with 4 cargo tie-downs, tailgate, 2-position (Locking feature not available on Regular or Extended Cab models.) | Standard |
| Suspension Package, Heavy-Duty | Standard |
| Automatic Crash Response (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, engine temperature, tachometer and Driver Information Center | Standard |
| Door locks, child security rear (Crew Cab models only) | Standard |
| Suspension, front independent with torsion bar (Not available on 2WD Regular Cab models. Standard on 4WD models. Included with (Z71) High Stance Off-Road Suspension Package. Included on 2WD Extended and Crew Cab models with (Z85) Heavy-Duty Suspension Package and (LH9) 5.3L V8 SFI engine.) | Standard |
| Theft-deterrent system, vehicle, PASSlock | Standard |
| LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats (Not available on Regular Cab models.) | Standard |
| Air dam, Ebony | Standard |
| Coat hook, driver-side rear | Standard |
| Power Convenience Package with power windows, power door locks with lockout protection, Remote Keyless Entry, (DE6) outside power-adjustable, manual-folding mirrors and (DF5) inside rearview auto-dimming mirror with compass and temperature display | Standard |
| Fog lamps, front, halogen | Standard |
| Air conditioning, single-zone manual | Standard |
| GVWR, 5300 lbs. (2404 kg) (Not available on Regular Cab models. Included and only available with (Z71) High Stance Off-Road Suspension Package on 2WD models. Standard on 4WD Extended and Crew Cab models. Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Four wheel drive | Standard |
| Visors, driver and front passenger, padded with cloth includes front passenger vanity mirror | Standard |
| Assist handle, front passenger and rear outboard (Crew Cab models only.) | Standard |
| Accents, interior Titanium Nova Silver-colored air outlets and center control stack with chrome door handle bezels, uplevel instrument cluster bezel, front upper door speaker bezel and air vent sliders | Standard |
| Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield, driver and front passenger-side glass) | Standard |
| Alternator, 125 amps | Standard |
| Bedliner | Standard |
| Trailering equipment includes (VR4) trailer hitch and (UY7) 7-pin sealed trailer wiring connector (Not available with (LLV) 2.9L DOHC 4- cylinder SFI engine. Required on Crew Cab models with (LLR) 3.7L DOHC 5-cylinder engine or (LH9) 5.3L V8 SFI engine.) | Standard |
| Transfer case, Insta-Trac electronic shift with dash-mounted controls (4WD models only.) | Standard |
| Stolen Vehicle Assistance (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| StabiliTrak (Includes traction control.) | Standard |
| SiriusXM Satellite Radio is standard on nearly all 2012 GM models. Enjoy a 3-month trial to the 'XM Select' package, with over 170 channels including commercial-free music, all your favorite sports, exclusive talk and entertainment. And now add premium channels to your trial at no-cost. Welcome to the world of satellite radio. (Requires a subscription sold separately by SiriusXM after the trial period. If you decide to continue your service at the end of your subscription, service will automatically renew and bill, at the rates in effect at the time of renewal, until you call SiriusXM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm.com. Available only to those at least 18 and older in the 48 contiguous USA and D.C.) | Standard |
| Mirror, inside rearview auto-dimming with compass and outside temperature display | Standard |
| Trailer hitch | Standard |
| Bumpers, front and rear chrome with a Dark Smoke Gray pad on the rear step-style bumper | Standard |
| Bluetooth for Phone (Deleted when (UE0) OnStar delete is ordered.) | Standard |
| Floor mats, rubberized-vinyl front and rear | Standard |
| Safety belts, 3-point, rear, all seating positions (Not available on Regular Cab models.) | Standard |
| Tailgate, 2-position | Standard |
| Engine, 3.7L DOHC 5-cylinder SFI (242 hp [180.4 kW] @ 5600 rpm), 242 lb-ft [326.7 N-m] @ 4600 rpm) (Standard on 4WD Regular and Crew Cab models. Refer to the Engine and Axle section for compatibility requirements. Must specify.) | Standard |
| Battery, heavy-duty 590 cold-cranking amps, maintenance-free with rundown protection | Standard |
| Air bags, frontal, driver and right-front passenger with Passenger Sensing System (A note about child safety: Always use safety belts and the correct child restraint for your child's age and size. Even with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See your vehicle Owner's Handbook for more information.) | Standard |
| Daytime Running Lamps with automatic exterior lamp control | Standard |
| Mirrors, outside power-adjustable, manual-folding, body-color | Standard |
| Floor covering, Ebony carpeting | Standard |
